CVM-B150-ITF-HF
5�3�- ALARM MENU
The screen in
is the alarm display menu screen. Where all the alarms programmed in the
Figure 145
device and in the connected expansion modules are displayed, indicating a brief description and the
date and time of the alarm activation.
Figure 145: Main screen of alarm menu�
The alarm selected is indicated in white.
>
>
<
>
<
<
Main
menu
Next
1
Unlock
Previous
alarm
Disabled latch
>
>
<
<
Figure 146:Alarm menu�
.Disabled latch, displayed when the alarm selected does not have the latch option enabled.
Unlock alarm, if the latch option has been programmed in an alarm and it has been activated, the
alarm will be unlocked with this option.
Use the keys
and
to select the different options.
To confirm the selection, press the key
.
Instruction Manual
105
