3�3�2�- TERMINALS ON THE LOWER FACE
~ +
20 : , Auxiliary power supply.
~ -
21: , Auxiliary power supply.
22: S1 Current input L1
,
23: S2, Current input L1
24: S1
Current input L2
,
12
Table 4:List of terminals on the lower face of the CVM-B150�
Device terminals
20
22 23 24 25 26 27 28 29
Figure 2:CVM-B150 terminals, lower face�
25: S2, Current input L2
26: S1 Current input L3
,
27: S2, Current input L3
28: S1, Neutral current input, LN
29: S2, Neutral current input, LN
21
