1.6
About This Manual
1.6.1
Version Control
Version 2.2
LT-980
If you connect to the ethernet TCP/IP network with the TX3 Configurator, you
can configure any of the nodes in the system. If you connect direcly to a controller
using USB, a modem, or a COM port, you will only be able to configure devices
that are on the same RS-485 subnetwork as that device.
Note:
There can only be one Master Node on an RS-485 subnetwork. That
is, you cannot connect one RS-485 subnetwork to another RS-485
subnetwork. However, if you want to connect to a Touch Screen
panel remotely over the Internet (for instance, to configure Touch
Screen options such as color and themes), the Touch Screen panel
must be set as an Master Node even if there is no slave panel
connected to it.
This manual provides comprehensive information on the installation and
configuration of the Card Access System by the installation technician. Tasks are
described in the order that they are likely to be performed.
Chapter 2 describes the installation of the controller.
Chapter 3 describes the configurable modes of operation.
This manual applies to the following models:
•
TX3-CX-2K-A IP Capable Two Door Card Access Controller Kit
•
TX3-CX-2-A IP Capable Two Door Card Access Controller
The version number appears on the front cover and changes whenever there is a
major or minor update to any part of the system regarding operation or
configuration.
The following convention indicates major or minor changes:
Initial release. Version 1.00.0
Major change. Version 2.00.0
Minor change. Version 2.01.0
Pre-release changes. Version 2.01.1
TX3-CX Card Access System Installation and Operation Manual
Copyright 2015
Welcome
13 (61)
