If you connect to the Ethernet TCP/IP network with the TX3 Configurator, you
can configure any of the nodes in the system. If you connect directly to a
controller using USB, a modem, or a COM port, you will only be able to
configure devices that are on the same RS-485 subnetwork as that device.
Note:
1.6

About This Manual

This manual applies to the following models:
•
•
•
•
•
•
•
•
1.6.1 Additional Documentation
For additional documentation, see the following Mircom literature:
•
•
•
•
•
•
•
•
TX3-CX Card Access System Installation and Operation Manual
Version 5.2
LT-980 Copyright 2019
There can only be one Master Node on an RS-485 subnetwork.
That is, you cannot connect one RS-485 subnetwork to another
RS-485 subnetwork. However, if you want to connect to a
Touch Screen panel remotely over the Internet (for instance, to
configure Touch Screen options such as color and themes), the
Touch Screen panel must be set as an Master Node even if there
is no slave panel connected to it.
TX3-CX-2K Two Door Card Access System Kit
TX3-CX Two Door Card Access Controller
TX3-CX-2K-A IP Capable Two Door Card Access Controller Kit
TX3-CX-4K-A IP Capable Four Door Card Access Controller Kit
TX3-CX-6K-A IP Capable Six Door Card Access Controller Kit
TX3-CX-8K-A IP Capable Eight Door Card Access Controller Kit
TX3-CX-2-A IP Capable Two Door Card Access Controller (non-UL
listed version)
TX3-BBCX-4W Cabinet
LT-6618 TX3-CX-1 Installation Manual
LT-969 TX3 Telephone Access System Installation and Operation
Manual
LT-968 TX3 Telephone Access System User's Guide
LT-971 TX3-MDM Modem Module Installation
LT-1161 TX3-IP IP Module Installation Instructions
LT-5997 TX3-CX-1NP Installation
LT-9940 TX3 Elevator Restriction Manual
LT-995 TX3 System Configuration and Administration Manual
Welcome
11
