3.6.3
Card Reader Status LEDs
3.6.4
Card Reader Beeper
3.7
Setting DIP Switches SW2
Version 2.2
LT-980
Card Reader A. Connections required for card reader A (starting from the far
bottom left side) are Beeper, Red LED, Green LED, PWR(+), COM(-), Data 0,
Data 1 and COM (-).
Card Reader B. Card reader B follows the same terminal connections, located
to the right of the card reader A terminals.
Note:
When using card readers with a single LED control connect the
control wire to the green LED terminal.
There are three status LEDs on the card reader:
Green LED. Illuminates steady green when door is unlocked.
Red LED. Illuminates steady red when door is locked.
Orange LED. Illuminates steady orange until a card is used for the first time.
Normal illumination returns upon subsequent use. (on some models only)
The beeper indicates specific events at different beep rates as follows:
Card Presented. One short beep.
Access Granted. Two short beeps.
Access Denied. One short beep and one long beep.
Mode of Operation Changed. Three short beeps indicate a change in the on or
off state for the high security or the unlock mode.
Alarm. Continuous short beeps.
The DIP switches on SW2 are used to set the Card Access Controller address on
the RS-485 network and determin how the Card Access Controller gets its IP
address (on IP enabled controllers only). Valid addresses are 1 to 63. DIP
switches 1 to 6 are used for binary addressing with DIP switch 1 being the least
significant bit. DIP switch SW2 is found at the top central portion of the Card
Access Controller board, see Figure 9.
TX3-CX Card Access System Installation and Operation Manual
Copyright 2015
Installation and Setup
47 (61)
