ASSEMBLY OF THE RECOVERY UNIT INTAKE GRILLE
1 Remove the external grille in order to gain access to the fixing holes..
Remove the upper part of the external ventilation grille. (see pic. 1)
MODELLO
PICO CLEAN WI 30
PICO CLEAN WI 55
PICO CLEAN WI 80
fig.1
2 Insert the wall plugs provided in the holes.
External grille mounted
Ventilation
Solutions
Accessories
For Heating
DIMENSIONI (mm)
B H
154 110 15
186 142 15
186 142 15
Multi - Zone
Air Control System
Instruments &
Tools
L L1 L2
45 87
45 101
50 101
Grey front part
pic.1
DIAMETRO (D)
100 1,2
125 1,2
150 1,2
fig.2
Grey back part
