ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Designator
18 C85, C90 to C94, C101 to C103,
C107, C108, C110, C115, C116,
C121, C127, C132, C134
50 C1, C2, C5, C7 to C10, C20, C21,
C28, C29, C38, C42, C48 to C51,
C58 to C60, C62, C64, C69, C73,
C76, C79, C82, C97, C99, C112,
C118, C122, C128, C135, C146,
C147, C149, C151, C155, C156,
C158, C162, C168, C174, C176,
C177, C193, C194, C197, C203
9 C37, C65, C67, C83, C88, C124,
C129, C157, C160
12 R28, R30, R51, R59, R166, R167,
R169, R172, R185, R189, R212,
R214
8 C68, C71, C87, C89, C130, C138,
C159, C161
16 R24, R31, R44, R60, R77, R84, R93,
R106, R136, R149, R159, R170,
R180, R191, R207, R217
1 C84
32 R6, R7, R13, R14, R18, R20, R40,
R43, R47 to R49, R54, R55, R63,
R64, R74, R78, R80, R82, R158,
R164, R186, R224 to R227, R232 to
R237
3 C6, C39, C40
12 C15 to C17, C81, C86, C95, C98,
C170, C175, C178, C180, C183
12 C104, C106, C109, C111, C117,
C123, C140 to C145
5 C3, C4, C74, C96, C126
4 C61, C77, C113, C150
1 R117
3 D1, D3, D4
9 C23, C33, C43, C55, C114, C166,
C184, C188, C200
1 C36
2 C153, C154
8 R76, R81, R90, R101, R134, R141,
R157, R168
2 R1, R4
10 R91, R94, R98, R99, R108, R109,
R114, R115, R118, R123
Description
Multilayer ceramic capacitor,16 V, X7R
(0402)
Multilayer ceramic capacitor, 50 V, X7R
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Chip resistor, 100 kΩ, 1%, 125 mW, thick
film (0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Chip resistor, 100 kΩ, 1%, 100 mW, thick
film (0603)
Aluminum electrolytic capacitor, 100 μF,
16 V, FC 105 deg, SMD_E
Chip resistor, 10 kΩ, 1%, 125 mW, thick film
(0603)
Multilayer ceramic capacitor, 25 V, NP0
(0603)
Multilayer ceramic capacitor, 100 V, NP0
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0402)
Aluminum electrolytic capacitor, 16 V, FC
105 deg, SMD_B
Multilayer ceramic capacitor, 50 V NP0
(0603)
Chip resistor, 1 kΩ, 1% 125 mW thick film
(0603)
TVS Zener, 15 V, 600 W, SMB
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0805)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Chip resistor, 237 Ω, 1%, 125 mW, thick film
(0603)
Chip resistor, 243 Ω, 1%, 100 mW, thick film
(0603)
Chip resistor, 24.9 Ω, 1%, 63 mW, thick film
(0402)
Rev. 0 | Page 27 of 32
Manufacturer Part Number
Panasonic EC ECJ-0EX1C104K
Panasonic EC ECJ-1VB1H104K
Panasonic EC ECJ-1VC1H102J
Panasonic EC ERJ-3EKF1003V
Panasonic EC ECJ-1VC1H101J
Panasonic EC ERJ-3EKF1000V
Panasonic EC EEE-FC1C101P
Panasonic EC ERJ-3EKF1002V
TDK Corp C1608C0G1E103J
Panasonic EC ECJ-1VC2A100D
Kemet C0402C100J5GACTU
Panasonic EC EEE-FC1C100R
Panasonic EC ECJ-1VC1H121J
Panasonic EC ERJ-3EKF1001V
ON Semiconductor 1SMB15AT3G
Murata Electronics GRM1885C1H222JA01D
Murata ENA GRM21B5C1H223JA01L
Panasonic EC ECJ-1VC1H220J
Panasonic EC ERJ-3EKF2370V
Panasonic EC ERJ-3EKF2430V
Rohm MCR01MZPF24R9
UG-040
