Analog Devices EVAL-AD1937AZ User Manual page 28

UG-040
Qty Designator
16 R56, R57, R65, R66, R88, R89, R140,
R154, R179, R183, R213, R216,
R228 to R231
16 C24, C25, C31, C34, C44, C45, C53,
C56, C167, C169, C181, C185,
C189, C190, C198, C201
3 R3, R11, R58
1 C125
4 R5, R52, R53, R75
1 C120
33 R21, R22, R26, R27, R33 to R35,
R37 to R39, R41, R46, R50, R62,
R68, R69, R71, R173, R176, R182,
R184, R193, R195, R197, R199,
R202, R204, R209, R211, R219 to
R221, R223
16 R23, R25, R32, R36, R42, R45, R61,
R70, R177, R181, R192, R198, R205,
R208, R218, R222
1 R129
23 C11, C13, C14, C26, C30, C46, C52,
C63, C66, C72, C75, C80, C105,
C119, C133, C139, C148, C152,
C164, C172, C179, C191, C196
3 C12, C18, C19
1 R12
4 R83, R96, R148, R163
20 R103, R104, R110 to R112, R116,
R119, R124, R126 to R128, R130 to
R132, R142 to R147
35 R8 to R10, R15 to R17, R19, R92,
R95, R100, R105, R113, R120, R125,
R133, R135, R139, R153, R155,
R156, R160, R174, R175, R178,
R187, R188, R190, R194, R196,
R200, R201, R203, R206, R210,
R215
1 C131
1 R138
16 R72, R73, R79, R85 to R87, R97,
R107, R121, R122, R137, R150 to
R152, R165, R171
4 C78, C137, C171, C195
1 R2
1 U11
2 U19, U26
1 R29
Description
Chip resistor, 24.9 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 100 V, NP0
(0603)
Chip resistor, 374 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Chip resistor, 392 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 16 V, ECH-U
(1206)
Chip resistor, 3.01 kΩ, 1%, 100 mW, thick
film (0603)
Chip resistor, 3.09 kΩ, 1%, 100 mW, thick
film (0603)
Chip resistor, 3.32 kΩ, 1%, 100 mW, thick
film (0603)
Aluminum electrolytic capacitor, 16 V,
FC 105 deg, SMD_D
Aluminum electrolytic capacitor FC 105 deg
SMD_E
Chip resistor, 499 Ω, 1%, 100 mW, thick film
(0603)
Chip resistor, 49.9 Ω, 1%, 100 mW, thick film
(0603)
Chip resistor, 49.9 Ω, 1%, 63 mW, thick film
(0402)
Chip resistor, 49.9 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 25 V, NP0
(0603)
Chip resistor, 562 Ω, 1%, 125 mW, thick film
(0603)
Chip resistor, 5.76 kΩ, 1%, 125 mW, thick
film (0603)
Multilayer ceramic capacitor, 100 V, NP0
(0603)
Chip resistor, 715 Ω, 1%, 100 mW, thick film
(0603)
IC inverter hex, TTL/LSTTL, 14 SOIC
IC buffer, quad three-state, 14 SOIC
Chip resistor, 75 Ω, 1%, 100 mW, thick film
Rev. 0 | Page 28 of 32
Evaluation Board User Guide
Manufacturer Part Number
Rohm MCR03EZPFX24R9
Murata ENA GRM1885C2A301JA01D
Rohm MCR03EZPFX3740
Panasonic EC ECJ-1VC1H391J
Rohm MCR03EZPFX3920
Panasonic EC ECH-U1C393JB5
Rohm MCR03EZPFX3011
Rohm MCR03EZPFX3091
Rohm MCR03EZPFX3321
Panasonic EC EEE-FC1C470P
Panasonic EC EEE-FC1E470P
Rohm MCR03EZPFX4990
Panasonic EC ERJ-3EKF4992V
Rohm MCR01MZPF49R9
Panasonic EC ERJ-3EKF49R9V
TDK Corp C1608C0G1E562J
Panasonic EC ERJ-3EKF5620V
Panasonic EC ERJ-3EKF5761V
Panasonic EC ECJ-1VC2A680J
Rohm MCR03EZPFX7150
NXP Semi 74HC04D-T
Texas Instruments SN74LV125AD
Panasonic EC ERJ-3EKF75R0V
