UG-040
Qty Designator
1 U10
2 U18, U22
1 U4
2 SW2, SW3
2 S2, S3
1 S6
1 U5
1 U7
69 TP1 to TP69
1 Q1
Description
110 Ω AES/EBU transformer
Buffer, three-state single gate
Octal, three-state buffer/driver
SPDT slide switch, PC mount
8-position, SPST SMD switch, flush,
actuated
Tact switch, 6 mm, gull wing
15 Mb/sec fiber optic receiving module
with shutter
15 Mb/sec fiber optic transmit module,
Mini test point, white, 0.1 inch, OD
100 V, medium power, low saturation
transistor, SOT223, NPN
Rev. 0 | Page 30 of 32
Evaluation Board User Guide
Manufacturer Part Number
Scientific SC937-02
Conversion
Texas Instruments SN74LVC1G125DRLR
Texas Instruments SN74LVC541ADBR
E-Switch EG1218
CTS 219-8LPST
Tyco/Alcoswitch FSM6JSMA
Toshiba TORX147L(F,T)
Toshiba TOTX147L(F,T)
Keystone 5002
Electronics
Zetex ZX5T953GTA
