Evaluation Board User Guide
Qty Designator
1 R67
16 C22, C27, C32, C35, C41, C47, C54,
C57, C165, C173, C182, C186,
C187, C192, C199, C202
1 Y1
1 U15
1 U23
1 U1
1 J2
1 J3
1 J4
2 J22, J23
1 U8
1 U13
2 D2, D5
1 S1
1 SW1
6 L2 to L7
1 L1
2 J1, J14
4 J15 to J18
1 J19
2 J20, J26
4 J5 to J8
2 S4, S5
16 JP4, JP11 to JP14, JP17, JP18, JP20
to JP22, JP24, JP26, JP28 to JP31
15 JP1 to JP3, JP5 to JP10, JP15, JP16,
JP19, JP23, JP25, JP27
1 U16
2 D8, D11
2 D6, D9
2 D7, D10
2 U2, U3
6 J10, J11, J13, J21, J27, J28
2 R161, R162
8 U6, U9, U12, U14, U17, U20, U24,
U25
1 R102
1 U21
2 J9, J12
Description
(0603)
Chip resistor, 90.9 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Crystal, 12.288 MHz, SMT, 10 pF
Four ADC/eight DAC with PLL, 192 kHz
Microprocessor voltage supervisor
Voltage regulator, low dropout
5-way binding post, black, uninsulated base
TH
5-way binding post, mini, green,
uninsulated base TH
5-way binding post, mini, red, uninsulated
base TH
SMA receptacle straight PCB mount
192 kHz digital audio receiver, 28-TSSOP
192 kHz digital audio, S/PDIF transmitter
Passivated rectifier, 1 A 50 V MELF
Switch slide, DP3T, PC MNT, L = 4 mm
DPDT slide switch, vertical
Chip ferrite bead, 600 Ω at 100 MHz
Chip ferrite bead, 600 Ω at 100 MHz
10-way shrouded polarized header
16-way unshrouded, not populated
Connector header, 0.100 dual STR, 72 POS
Connector header, 0.100 dual STR, 72 POS
Connector header, 0.100 dual STR, 72 POS
16-position rotary switch hex
2-pin header, unshrouded jumper, 0.10";
use shunt Tyco 881545-2
3-position SIP header
Complex programmable logic device
(CPLD), HI PERF E2CMOS PLD
Green, diffused, 10 millicandela, 565 nm
(1206)
Red, diffused, 6.0 millicandela, 635 nm
(1206)
Yellow, diffused, 4.0 millicandela, 585 nm
(1206)
3-terminal adjustable voltage regulator,
DPak
Stereo mini jack SMT
Resistor network, bussed 8 res, 9 pin
Dual bipolar/JFET audio op amp
Not populated
12.288 MHz fixed SMD oscillator, 1.8 V dc to
3.3 V dc
RCA jack PCB TH mount R/A yellow
Rev. 0 | Page 29 of 32
Manufacturer Part Number
Rohm MCR03EZPFX90R9
Murata ENA GRM1885C1H911JA01D
Abracon Corp ABM3B-12.288MHZ-10-
1-U-T
Analog Devices AD1939YSTZ
Analog Devices ADM811RARTZ
Analog Devices ADP3303ARZ-3.3
Deltron 552-0100 BLK
Components
Deltron 552-0400 GRN
Components
Deltron 552-0500 RED
Components
Amp-RF Division 901-144-8RFX
Cirrus Logic CS8416-CZZ
Cirrus Logic CS8406-CZZ
Micro Commercial DL4001-TP
E-Switch EG2305
E-Switch EG2207
TDK MPZ1608S601A
Steward HZ0805E601R-10
3M N2510-6002RB
3M N/A
Sullins PBC10DAAN; or cut
PBC36DAAN
Sullins PBC13DAAN; or cut
PBC36DAAN
Sullins PBC06DAAN; or cut
PBC36DAAN
APEM PT65503
Sullins PBC02SAAN; or cut
PBC36SAAN
Sullins PBC03SAAN; or cut
PBC36SAAN
Lattice LC4128V-75TN100C
Semiconductor
Lumex Opto SML-LX1206GW-TR
Lumex Opto SML-LX1206IW-TR
CML Innovative CMD15-21VYD/TR8
Tech
STMicroelectronics LM317MDT-TR
CUI SJ-3523-SMT
CTS 773091103
Analog Devices OP275GSZ
N/A N/A
Abracon Corp AP3S-12.288MHz-F-J-B
Connect-Tech CTP-021A-S-YEL
Products
UG-040
