AD9776/AD9778/AD9779
0.1μF
LVDS_P_IN
LVDS_N_IN
0.1μF
Figure 68. LVDS DACCLK Drive Circuit
If a clean sine clock is available, it can be transformer-coupled
to DACCLK, as shown in Figure 68. Use of a CMOS or TTL
clock is also acceptable for lower sample rates. It can be routed
through a CMOS to LVDS translator, then ac-coupled, as
described in this section. Alternatively, it can be transformer-
coupled and clamped, as shown in Figure 69.
0.1μF
TTL OR CMOS
CLK INPUT
Figure 69. TTL or CMOS DACCLK Drive Circuit
A simple bias network for generating VCM is shown in
Figure 70. It is important to use CVDD18 and CGND for the
clock bias circuit. Any noise or other signal that is coupled onto
the clock is multiplied by the DAC digital input signal and can
degrade the DAC's performance.
1kΩ
287Ω 0.1μF
Figure 70. DACCLK VCM Generator Circuit
Internal PLL Clock Multiplier/Clock Distribution
The internal clock structure on the devices allows the user to
drive the differential clock inputs with a clock at 1× or an
integer multiple of the input data rate or at the DAC output
sample rate. An internal PLL provides input clock multipli-
cation and provides all the internal clocks required for the
interpolation filters and data synchronization.
The internal clock architecture is shown in Figure 71. The
reference clock is the differential clock at Pins 5 and 6. This
clock input can be run differentially or singled-ended by
driving Pin 5 with a clock signal and biasing Pin 6 to the
midswing point of the signal at Pin 5. The clock architecture
can be run in the following configurations:
1. PLL Enabled (Reg. 0x09, Bit 7 = 1). The PLL enable switch
shown in Figure 71 is connected to the junction of the N1
dividers (PLL VCO divide ratio) and N2 dividers (PLL
loop divide ratio). Divider N3 determines the interpo-
CLK+
50Ω
V = 400mV
CM
50Ω
CLK–
50Ω
CLK+
CLK–
50Ω
BAV99ZXCT
HIGH SPEED
DUAL DIODE
V = 400mV
CM
V = 400mV
CM
CVDD18
1nF
1nF
CGND
lation rate of the DAC, and the ratio N3/N2 determines the
ratio of reference clock/input data rate. The VCO runs
optimally over the range of 1.0 GHz to 2.0 GHz, so that N1
keeps the speed of the VCO within this range, although the
DAC sample rate can be lower. The loop filter components
are entirely internal and no external compensation is
necessary.
2. PLL Disabled (Reg. 0x09, Bit 7 = 0). The PLL enable switch
shown in Figure 71 is connected to the reference clock
input. The differential reference clock input is the same as
the DAC output sample rate. N3 determines the
interpolation rate.
REFERENCE CLOCK
(Pins 5 and 6)
DETECTION
PLL ENABLE
Table 17. VCO Frequency Range vs. PLL Band Select Value
PLL Band
Select
111111 (63)
111110 (62)
111101 (61)
111100 (60)
111011 (59)
111010 58)
111001 (57)
111000 (56)
110111 (55)
110110 (54)
110101 (53)
110100 (52)
110011 (51)
110010 (50)
110001 (49)
110000 (48)
101111 (47)
101110 (46)
101101 (45)
101100 (44)
