PHY1_TXCK
PHY1_TXD0
PHY1_TXD1
PHY1_TXD2
PHY1_TXD3
PHY1_TXCTL
PHY1_RXCK
PHY1_RXD0
PHY1_RXD1
PHY1_RXD2
PHY1_RXD3
PHY1_RXCTL
PHY1_MDC
PHY1_MDIO
PHY2_TXCK
PHY2_TXD0
PHY2_TXD1
PHY2_TXD2
PHY2_TXD3
PHY2_TXCTL
PHY2_RXCK
PHY2_RXD0
PHY2_RXD1
PHY2_RXD2
PHY2_RXD3
PHY2_RXCTL
PHY2_MDC
PHY2_MDIO
PHY2_RESET

Part 3.6: USB to Serial Port

The AXU3EGB carrier board is equipped with two Uart to USB ports, one
is connected to the PS end, and one is connected to the PL end.
The conversion chip uses Silicon Labs CP2102GM's USB-UAR chip, and
www.alinx.com
PS_MIO64
PS_MIO65
PS_MIO66
PS_MIO67
PS_MIO68
PS_MIO69
PS_MIO70
PS_MIO71
PS_MIO72
PS_MIO73
PS_MIO74
PS_MIO75
PS_MIO76
PS_MIO77
B66_L17_N
B66_L18_P
B66_L18_N
B66_L23_P
B66_L23_N
B66_L24_N
B66_L14_P
B66_L19_N
B66_L19_P
B66_L17_P
B66_L24_P
B66_L22_N
B66_L21_N
B66_L22_P
B66_L14_N
AXU3EGB User Manual
E19 Ethernet 1 RGMII Transmit Clock
A18 Ethernet 1 Transmit data bit0
G19 Ethernet 1 Transmit data bit1
B18 Ethernet 1 Transmit data bit2
C18 Ethernet 1 Transmit data bit3
D19 Ethernet 1 Transmit Enable Signal
C19 Ethernet 1 RGMII Receive Clock
B19 Ethernet 1 Receive Data Bit0
G20 Ethernet 1 Receive Data Bit1
G21 Ethernet 1 Receive Data Bit2
D20 Ethernet 1 Receive Data Bit3
A19 Ethernet 1 Receive Enable Signal
B20 Ethernet 1 MDIO Clock Management
F20 Ethernet 1 MDIO Management Data
E8 Ethernet 2 RGMII Transmit Clock
E9 Ethernet 2 Transmit data bit0
D9 Ethernet 2 Transmit data bit1
A9 Ethernet 2 Transmit data bit2
A8 Ethernet 2 Transmit data bit3
B9 Ethernet 2 Transmit Enable Signal
E5 Ethernet 2 RGMII Receive Clock
A5 Ethernet 2 Receive Data Bit0
B5 Ethernet 2 Receive Data Bit1
F8 Ethernet 2 Receive Data Bit2
C9 Ethernet 2 Receive Data Bit3
B8 Ethernet 2 Receive Enable Signal
A6 Ethernet 2 MDIO Clock Management
C8 Ethernet 2 MDIO Management Data
D5 Ethernet 2 Reset Signal
