Teldat S.A.
Underside panel
Fig. 7:
Underside panel components
Item
A
3.2 Mounting an anti-theft security cable
RS1800 series devices feature a standard Kensington security slot for optionally attaching a security cable. The T-
bar lock of the security cable allows the device to be attached to an anchor point, thus preventing potential thefts.
The security slot is located on the rear panel of the housing, as shown in the following figure:
Security Slot
Fig. 8:
3.3 Rack installation
The RS1800 series device can be installed in a 19" rack. The rack mounting brackets and screws are not provided
by default and must be acquired separately.
Both mounting brackets are attached to the device by means of 5 screws, as shown in the following figure:
Rack anchors
Fig. 9:
RS1800 series
Description
Adhesive rubber feet (these are not required for rack mounting).
3 Components and Power Supply
11
