When the MultiSight is powered up, the image shown in the
"Image" section of the computer software is the last image
recorded. For setting up a new inspection, click on the "Reset"
Command button. To view and continuously update the live
image, click the "Live Image" button.
To bring the object into focus, turn the
focusing screw on the back of the sensor.
To improve the contrast, use the "Shutter" in "Detector
Parameters."
Set up:
Select Detector Type to be "Pattern Match" in the "Detector
Parameters" section.
Set region of interest (ROI) by double clicking on the yellow box
and placing it on the image. This is the area in which the
MultiSight will look for the taught pattern.
Set pattern by double clicking on the red frame and placing it
on the image where the inspection needs to be performed.
IMPORTANT
In most cases, the majority of the parameters can be set using the
standard settings. A different setting may be necessary to
improve detection or shorten cycle times.
