MultiSight™ User Manual
Start-up

Program Description

Menu

The menu for the PC program has main and subsections. These are selected by clicking the desired menu item or by pressing the ALT
key and the first letter of the menu item at the same time.

File/Exit

Exit program.

Options/Language

Select language. The new language does not take effect until the software is restarted. (Currently English is the only available
language.)
Options/Result Display
(Keyboard Locked)
The "Result" window is shown enlarged in a pop-up window. This mode locks the keyboard and limits the mouse pointer to the pop-
up window.
IMPORTANT

Help/Help

Display the help file (a pdf of the User Manual).

Help/About

Displays software version number.
22
This mode can only be de-activated by placing the mouse pointer
over the Result indicator (the grey, green, or red circle next to the
top bar graph) and pressing the key combination ALT + B at the
same time.
