4.2.4 Integrated Peripherals

This option sets the hard disk configuration, mode and port.
Phoenix – AwardBIOS CMOS Setup Utility
On-Chip Local Bus IDE
IDE Buffer for DOS & Win
The 2 nd Channel IDE
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Secondary Master PIO
IDE Secondary Slave PIO
IDE HDD Block Mode
KBC Input Clock
Onboard FDD Controller
Onboard Serial Port 1
Onboard Serial Port 2
Onboard IR Controller
IR Address Select
IR Mode
IR Transmission delay
IR IRQ Select
IR MODE Use DMA
Onboard Parallel Port
Parallel Port Mode
XECP Mode Use DMA
XParallel Port EPP Type
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F7: Optimized Defaults
Award BIOS Utility
Integrated Peripherals
Enabled
Enabled
Enabled
Auto
Auto
Auto
Auto
Enabled
8MHz
Enabled
3F8/IRQ4
2F8/IRQ3
Disabled
3E0H
IrDA
Enabled
IRQ 10
Disabled
378/IRQ7
Normal
3
EPP1.9
Item Help
Menu Level
