AXIOMTEK AIE100-ONA Series User Manual

Edge ai embedded system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIE100-ONA Series
Edge AI Embedded System
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIE100-ONA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK AIE100-ONA Series

Summary of Contents for AXIOMTEK AIE100-ONA Series

  • Page 1 AIE100-ONA Series Edge AI Embedded System User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update any information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any forms or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permissions of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The AIE100-ONA does not come with an operating system which must be loaded first before installation of any software into the computer. Be sure to ground yourself to prevent static charge when installing any internal components.

  • Page 4: Classification

    Classification Degree of production against electric shock: not classified Degree of protection against ingress of water: IP40 (IP42 rating by optional cover kit) Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Mode of operation: Continuous Note: All of I/O connectors should be connected with corresponding cables when the system is operating with IP40 &...

  • Page 5: General Cleaning Tips

    General Cleaning Tips Please keep the following precautions in mind while understanding the details fully before and during any cleaning of the computer and any components within. A piece of dry cloth is ideal to clean the device. Be cautious of any tiny removable components when using a vacuum cleaner to absorb dirt on the floor.

  • Page 6: Scrap Computer Recycling

    If the computer equipment’s needs the maintenance or are beyond repair, we strongly recommended that you should inform your Axiomtek distributor as soon as possible for the suitable solution. For the computers that are no longer useful or no longer working well, please contact your Axiomtek distributor for recycling and we will make the proper arrangement.

  • Page 7: Table Of Contents

    Table of Contents Disclaimers ......................ii Safety Precautions ....................iii Classification ......................iv General Cleaning Tips ................... v Scrap Computer Recycling ................... vi SECTION 1 INTRODUCTION................. 1 General Description ................1 System Specifications ............... 2 1.2.1 Product Specification ..................2 1.2.2 I/O System ......................
  • Page 8 This page is intentionally left blank. viii...

  • Page 9: Section 1 Introduction

    AIE100-ONA Series User’s Manual SECTION 1 INTRODUCTION This chapter contains general information and detailed specifications of the AIE100-ONA. The Chapter 1 includes the following sections: ◼ General Description ◼ System Specifications ◼ Dimensions ◼ I/O Outlets ◼ Packing List ◼...

  • Page 10: System Specifications

    AIE100-ONA Series User’s Manual ⚫ Reliable and Stable Design The AIE100-ONA adopts the advanced fanless system and supporting the PCIex4 NVMe through M.2 interface, which makes it especially suitable for AI computing environments, best for smart city, GPU-accelerated processing, edge computing and smart retail applications.

  • Page 11: I/O System

    AIE100-ONA Series User’s Manual 1.2.2 I/O System ⚫ One HDMI 2.1 for display (Resolution: up to 3840x2160 @ 30 Hz) ⚫ One RJ-45 connector for 10/100/1000 Base-T Ethernet port ⚫ One RJ-45 connector for 10/100/1000 Base-T PoE (IEEE 802.3af; PSE), max. up to 15.4 Watts...

  • Page 12: System Specification

    AIE100-ONA Series User’s Manual 1.2.3 System Specification ⚫ Watchdog Timer ® ◼ Built-in NVIDIA Jetson Orin™ Nano ⚫ Power Supply ◼ Input : 12VDC ⚫ Operation Temperature ◼ -25°C to +70°C (-13°F to +158°F) (Power Mode: 15W) ⚫ Humidity ◼...

  • Page 13: Dimensions

    AIE100-ONA Series User’s Manual Dimensions The following diagrams show you dimensions and outlin es of the AIE100-ONA. 1.3.1 System Dimension Introduction...

  • Page 14: Wall Mount Bracket Dimension (Screw: M3 *4L 4Pcs)

    AIE100-ONA Series User’s Manual 1.3.2 Wall mount Bracket Dimension (Screw: M3 *4L 4pcs) Introduction...

  • Page 15: Din-Rail Mount Bracket Dimension (Screw: M3 *4L 8Pcs)

    AIE100-ONA Series User’s Manual 1.3.3 Din-rail mount Bracket Dimension (Screw: M3 *4L 8pcs) Introduction...

  • Page 16: Vesa Arm Mount Bracket Dimension (Screw: M3 *4L 4Pcs)

    AIE100-ONA Series User’s Manual 1.3.4 VESA arm mount Bracket Dimension (Screw: M3 *4L 4pcs) Introduction...

  • Page 17: I/O Outlets

    AIE100-ONA Series User’s Manual I/O Outlets The following figures show you I/O outlets on front view of the AIE100-ONA. ⚫ Front View drawing ⚫ Rear View drawing Introduction...

  • Page 18: Packing List

    1 HDMI, 1 GbE LAN, 1 GbE PoE and 2 USB Fanless Edge AI System with NVIDIA® Jetson Orin™ Nano 8GB, AIE100-ONA-8GB 1 HDMI, 1 GbE LAN, 1 GbE PoE and 2 USB If you cannot find this package or any items are missing, please contact Axiomtek distributors immediately. Introduction...

  • Page 19: Section 2 Hardware Installation

    Note: Waterproof capability of the IPX2 rating may be affected if a system is dissembled or improperly assembled; under such circumstances Axiomtek shall not be liable for any quality deterioration. Besides assembling the optional IP42 rating cover kit, please refer to...

  • Page 20: Installing The Pci Express Mini Card

    AIE100-ONA Series User’s Manual Installing the PCI Express Mini Card Step 1 Turn off the system, and unplug the power adaptor. Step 2 Turn the system upside down to locate screws at the bottom side as red marked and loosen four screws.
  • Page 21 AIE100-ONA Series User’s Manual Step 4 Holding the PCI Express mini card at a 45 degree angle up from horizontal, slowly insert the golden fingers into the PCI Express slot until it is fully inserted in. Step 5 Press it down gently, but firmly, and then secure the PCI Express mini card to the carrier by tightening up the one M2 Phillips screw to the marked position.

  • Page 22: Installing Lte Or Wi-Fi Antenna Cable

    AIE100-ONA Series User’s Manual Installing LTE or Wi-Fi Antenna Cable Step 1 Install the Mini PCIe card into the Mini PCIe slot and affix it with a screw. For more details, please refer to section 2.1: Installing the PCI Express Mini Card.
  • Page 23 AIE100-ONA Series User’s Manual Step 3 Install the antenna cable connector through the opening at the rear of the chassis. Step 4 Put the washer and Hex nut into the antenna cable connector, and tighten it up. Hardware Installation...
  • Page 24 AIE100-ONA Series User’s Manual Step 5 Connect the antenna cable to the PCI Express mini card. Hardware Installation...

  • Page 25: Installing The M.2 2280 Key M Ssd Drive

    AIE100-ONA Series User’s Manual Installing the M.2 2280 Key M SSD Drive Step 1 Turn off the system, and unplug the power adaptor. Step 2 Turn the system upside down to locate screws at the bottom side as red marked and loosen four screws.
  • Page 26 AIE100-ONA Series User’s Manual Step 4 Take 3pcs thermal pads out of its box. Step 5 Apply one thermal pad on the M.2 2280 Key M slot. Hardware Installation...
  • Page 27 AIE100-ONA Series User’s Manual Step 6 Holding the M.2 2280 Key M SSD drive at a 30 degree angle up from horizontal, slowly insert the golden fingers into the M.2 2280 Key M slot until it is fully inserted in.
  • Page 28 Please check M.2 thickness first to decide to apply how many pieces thermal pads on the M.2 SSD Drive, or please install the M.2 SSD Drive suggested by Axiomtek. Note:...

  • Page 29: Section 3 Jumper Setting & Connector

    AIE100-ONA Series User’s Manual SECTION 3 JUMPER SETTING & CONNECTOR Proper jumper settings configure the AIE100-ONA to meet your application purpose. We are here with listing a summary table of all jumpers and default settings for onboard devices, respectively. Jumper & Connector Location SBC87903 Top View Jumper setting &...
  • Page 30 AIE100-ONA Series User’s Manual SBC87903 Bottom View Note: We strongly recommended that you should not modify any unmentioned jumper setting without Axiomtek FAE’s instruction. Any modification without instruction might cause damage to the system. Jumper setting & connector...

  • Page 31: Connectors

    Connectors connect the board with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected. Here is a summary table shows you all connectors and button on the AIE100-ONA Series. External Connectors / Buttons...

  • Page 32: Digital I/O Connector (Cn2) (Optional)

    AIE100-ONA Series User’s Manual 3.2.1 Digital I/O Connector (CN2) (Optional) The AIE100-ONA supports one 8-Channel digital I/O connector by option. The digital I/O is controlled via software programming. Signal Signal DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 DIO7 DIO8 +5V_SBY 3.2.2...

  • Page 33: Usb2.0 & Usb3.2 Gen2 Connector (Cn5)

    AIE100-ONA Series User’s Manual 3.2.3 USB2.0 & USB3.2 Gen2 Connector (CN5) The Universal Serial Bus connectors are compliant with USB 2.0 (480Mbps) and USB 3.2 Gen2 (10Gbps), and ideally for installing USB peripherals such as keyboard, mouse, scanner, etc. Signal...

  • Page 34: Pci-Express Mini Card Connector (Scn1)

    AIE100-ONA Series User’s Manual 3.2.5 PCI-Express Mini Card Connector (SCN1) The AIE100-ONA supports a full-size PCI-Express Mini Card slots. SCN1 is applying to either PCI-Express or USB 2.0 signal, and complies with PCI-Express Mini Card Spec. V1.2. Signal Signal Signal Signal +3.3V...

  • Page 35: 2280 Key M Pcie X4 Ssd Slot (Scn2)

    AIE100-ONA Series User’s Manual 3.2.6 M.2 2280 Key M PCIe x4 SSD slot (SCN2) The AIE100-ONA comes with one M.2 2280 Key M PCIe x4 NVMe SSD slot for storage. Signal Signal Signal Signal +3.3V +3.3V PEX3_RX- PEX3_RX+ LED_1# PEX3_TX- +3.3V...

  • Page 36: Sim Card Slot (Scn3)

    AIE100-ONA Series User’s Manual 3.2.7 SIM Card Slot (SCN3) AIE100-ONA comes with SIM Card Slot (SCN3) for inserting SIM Card. In order to work properly, the SIM Card must be used together with 3G/LTE module which would be inserted to PCI-Express Mini Card Connector ( SCN1). It is mainly used for 3G/LTE wireless network application.

  • Page 37: Ethernet Ports (Lan1, Lan2)

    AIE100-ONA Series User’s Manual 3.2.9 Ethernet Ports (LAN1, LAN2) ® The AIE100-ONA comes with two RJ-45 connectors: LAN1 (NVIDIA Jetson Orin™ Nano) and ® LAN2 (Intel I210-IT). LAN1 is a GbE port, but LAN2 is the GbE PoE port (non-isolated), which is compliant IEEE 802.3af class 3, and the total power budget is 15Watts maximum.

  • Page 38: Power Button & Reset Button (Sw1)

    AIE100-ONA Series User’s Manual 3.2.10 Power Button & Reset Button (SW1) Power button can allow users to either turn on the AIE100-ONA or forcibly shut down the system, and the reset button can allow users to reset AIE100-ONA during system abnormal situation.

  • Page 39: Debug Port Connector (Jp1)

    AIE100-ONA Series User’s Manual 3.2.13 Debug Port Connector (JP1) The JP1 is the serial debug port (UART Port0) for debugging purposes at software development. Signal UART2_TXD_3.3V UART2_RXD_3.3V 3.2.14 CMOS Battery Interface (BAT1) This connector is for CMOS battery interface. Signal +VBAT 3.2.15 Power and Storage LED Indicator (LED1)
  • Page 40 AIE100-ONA Series User’s Manual This page is intentionally left blank. Jumper setting & connector...

  • Page 41: Section 4 Jetpack Bsp Flash Method

    AIE100-ONA Series User’s Manual SECTION 4 JETPACK BSP FLASH METHOD This chapter provides users with a detailed description of how to flash NVIDIA Jetpack BSP for AIE100-ONA, the user could follow the below instruction to install or reinstall Jetpack BSP by themselves.
  • Page 42 AIE100-ONA Series User’s Manual Step3. If the check result returns OK, u ntar the image file with the command below: $ tar jxvf <image_tarball_file_name>.tbz2 Command Example: tar jxvf mfi_jetson-orin-nano-8GB-JP5.1.1-SBC87903-V1.0.0.tbz2 Step4. Change the directory to the image package folder with the command below: $ cd <image_file_name>...
  • Page 43 AIE100-ONA Series User’s Manual Step6. Running the following command to flash the image. $sudo ./tools/kernel_flash/l4t_initrd_flash.sh -- flash-only --massflash 5 Step7. The flashing procedure takes approximately 20 minutes or more. Once finished, and AIE100-ONA will automatically reboot, and please switch the recovery switch(SSW2) to OFF to return to standard mode.

  • Page 44: Image Information Inquiry Command

    AIE100-ONA Series User’s Manual Image Information Inquiry Command axiomtek.sh Running command to inquiry the current image information, image version, L4T version, Linux kernel version, and Ubuntu version. Jetpack BSP Flash Method...

  • Page 45: Jtop-Third-Party Jetson Platform Monitor Tool

    AIE100-ONA Series User’s Manual JTOP-Third-party Jetson Platform Monitor Tool JTOP is a third-party system monitoring utility that runs on the terminal and see and control realtime the status of the AIE Series Platform. CPU, RAM, GPU status, power mode management, toolkits version and more.
