Congatec conga-QEVAL/Qseven 2.0 User Manual page 37

PCI Express Slot 0-3 Pinout Description
PCI Express Slot 0/Link 0 Connector X11
Pin Signal Pin Signal
B1 PRSNT#1_S0
+12V A1
B2
+12V A2 +12V
B3 N.C.
A3 +12V
B4 GND GND
A4
B5 SMB_CLK N.C.
A5
B6 SMB_DAT N.C.
A6
B7 GND A7 N.C.
B8 N.C.
+3.3V A8
B9 N.C.
A9 +3.3V
B10 +3.3V Standby
A10 +3.3V
B11 WAKE0# PCIE_RST#
A11
B12 N.C. GND
A12
B13 GND PCIE1_CLK+
A13
B14 PCIE1_TX+ PCIE1_CLK-
A14
B15 PCIE1_TX- GND
A15
B16 GND PCIE1_RX+
A16
B17 PRSNT#2_S0 A17 PCIE1_RX-
B18 GND GND
A18
PCI Express Slot 2/Link 2 Connector X13
Pin Signal Pin Signal
B1 PRSNT#1_S2
+12V A1
B2
+12V A2 +12V
B3 N.C.
A3 +12V
B4 GND GND
A4
B5 SMB_CLK N.C.
A5
B6 SMB_DAT N.C.
A6
B7 GND A7 N.C.
B8 N.C.
+3.3V A8
B9 N.C.
A9 +3.3V
B10 +3.3V Standby
A10 +3.3V
B11 WAKE0# PCIE_RST#
A11
B12 N.C. GND
A12
B13 GND PCIE3_CLK+
A13
B14 PCIE3_TX+ PCIE3_CLK-
A14
B15 PCIE3_TX- GND
A15
B16 GND PCIE3_RX+
A16
B17 PRSNT#2_S2 A17 PCIE3_RX-
B18 GND GND
A18
Copyright © 2014 congatec AG
PCI Express Slot 1/Link 1 Connector X12
Pin Signal Pin Signal
B1 PRSNT#1_S1
+12V A1
B2
+12V A2 +12V
B3 N.C.
A3 +12V
B4 GND GND
A4
B5 SMB_CLK N.C.
A5
B6 SMB_DAT N.C.
A6
B7 GND A7 N.C.
B8 N.C.
+3.3V A8
B9 N.C.
A9 +3.3V
B10 +3.3V Standby
A10 +3.3V
B11 WAKE0# PCIE_RST#
A11
B12 N.C. GND
A12
B13 GND PCIE2_CLK+
A13
B14 PCIE2_TX+ PCIE2_CLK-
A14
B15 PCIE2_TX- GND
A15
B16 GND PCIE2_RX+
A16
B17 PRSNT#2_S1 A17 PCIE2_RX-
B18 GND GND
A18
PCI Express Slot 3/Link 3 Connector X14
Pin Signal Pin Signal
B1 PRSNT#1_S3
+12V A1
B2
+12V A2 +12V
B3 N.C.
A3 +12V
B4 GND GND
A4
B5 SMB_CLK N.C.
A5
B6 SMB_DAT N.C.
A6
B7 GND A7 N.C.
B8 N.C.
+3.3V A8
B9 N.C.
A9 +3.3V
B10 +3.3V Standby
A10 +3.3V
B11 WAKE0# PCIE_RST#
A11
B12 N.C. GND
A12
B13 GND PCIE4_CLK+
A13
B14 PCIE4_TX+ PCIE4_CLK-
A14
B15 PCIE4_TX- GND
A15
B16 GND PCIE4_RX+
A16
B17 PRSNT#2_S3 A17 PCIE4_RX-
B18 GND GND
A18
QEV2m11
x1 PCI Express
Connector
A1
B1
A2
B2
B3 A3
A4
B4
B5
A5
A6
B6
B7 A7
B8
A8
B9
A9
B10
A10
B11
A11
B12
A12
B13 A13
B14
A14
B15
A15
B16 A16
B17
A17
A18
B18
37/49
