5.2.13

PCI Express Mini Card

The QEVAL 2.0 is equipped with a PCI Express Mini Card socket. PCI Express Mini Card is a unique small size form factor optimized for mobile
computing platforms equipped with communication applications such as wireless LAN. The small footprint connector can be implemented on
carrier board designs providing the ability to insert different removable PCI Express Mini Cards. Using this approach gives the flexibility to
mount an upgradable, standardized PCI Express Mini Card device to the carrier board without additional expenditure of a redesign. The PCI
Express Mini Card utilizes USB port 2 and PCI Express link 0. The table below lists the default pinout of the PCI Express Mini Card
Mini PCI Express Pin Description.
Pin Signal
WAKE#
1
N.C.
3
N.C.
5
7 CLKREQ#
GND
9
REFCLK-
11
REFCLK+
13
GND
15
17 N.C.
N.C.
19
GND
21
PERn0
23
PERp0
25
27 GND
GND
29
31 PETn0
33 PETp0
GND
35
37 GND
+3.3Vaux
39
+3.3Vaux
41
GND
43
N.C.
45
47 N.C.
N.C.
49
N.C.
51
Note
To use a mini PCI Express card that supports USB signals, you must set DIP 3 of Switch SW9 to OFF. To use a mini PCI Express card that
Copyright © 2014 congatec AG
Pin Signal
+3.3Vaux
2
GND
4
6 +1.5V
N.C.
8
N.C.
10
N.C.
12
N.C.
14
N.C.
16
GND
18
W_DISABLE#
20
PERST#
22
+3.3Vaux
24
GND
26
28 +1.5V
SMB_CLK
30
SMB_DATA
32
GND
34
USB_D-
36
USB_D+
38
GND
40
LED_WWAN#
42
LED_WLAN#
44
LED_WPAN#
46
48 +1.5V
GND
50
+3.3Vaux
52
The PCI Mini Card socket has three different red LEDs to indicate the
presence of certain area network types. They are as follows:
LED Indicates
D9 WWAN Wireless Wide Area Network
D10 WLAN Wireless Local Area Network
D11 WPAN Wireless Personal Area Network
X31
M10
QEV2m11
D9-D11
SW9
O
1
Default Settings:
N
2
ALL OFF
3
4
