Congatec conga-QEVAL/Qseven 2.0 User Manual page 20

Pin Signal Description
161 PCIE3_TX+ PCI Express Channel 3 Output+
163 PCIE3_TX- PCI Express Channel 3 Output-
165 GND Power Ground
167 PCIE2_TX+ PCI Express Channel 2 Output+
169 PCIE2_TX- PCI Express Channel 2 Output-
171 UART0_TX Serial Data Transmitter
173 PCIE1_TX+ PCI Express Channel 1 Output+
175 PCIE1_TX- PCI Express Channel 1 Output-
177 UART0_RX Serial Data Receiver
179 PCIE0_TX+ PCI Express Channel 0 Output+
181 PCIE0_TX- PCI Express Channel 0 Output-
183 GND Power Ground
185 LPC_AD0 LPC Interface Address Data 0
/ GPIO0 General Purpose input/output 0
187 LPC_AD2 LPC Interface Address Data 2
/ GPIO2 General Purpose input/output 2
189 LPC_CLK LPC Interface Clock
/GPIO4 General Purpose input/output 4
191 SERIRQ Serialized interrupt
/GPIO6 General Purpose input/output 6
193 VCC_RTC 3V backup cell input
195 FAN_TACHOIN Fan tachometer input
/GP_TIMER_IN General Purpose Timer In
197 GND Power Ground
199 SPI_MOSI SPI Master serial output/Slave serial input
201 SPI_MISO SPI Master serial input/Slave serial output signal
203 SPI_SCK SPI Clock Output
205 VCC_5V_SB +5VDC,Standby ±5%
207 MFG_NC0 For manufacturing and debugging purposes
209 MFG_NC1 For manufacturing and debugging purposes
Power supply +5VDC ±5%
211 VCC
Power supply +5VDC ±5%
213 VCC
Power supply +5VDC ±5%
215 VCC
217 VCC Power supply +5VDC ±5%
Power supply +5VDC ±5%
219 VCC
Power supply +5VDC ±5%
221 VCC
Power supply +5VDC ±5%
223 VCC
Power supply +5VDC ±5%
225 VCC
227 VCC Power supply +5VDC ±5%
Power supply +5VDC ±5%
229 VCC
Copyright © 2014 congatec AG
Pin Signal
162 PCIE3_RX+
164 PCIE3_RX-
166 GND
168 PCIE2_RX+
170 PCIE2_RX-
172 UART0_RTS#
174 PCIE1_RX+
176 PCIE1_RX-
178 UART0_CTS#
180 PCIE0_RX+
182 PCIE0_RX-
184 GND
186 LPC_AD1
/ GPIO1
188 LPC_AD3
/ GPIO3
190 LPC_FRAME#
/GPIO5
192 LPC_LDRQ#
/GPIO7
194 SPKR
/GP_PWM_OUT2
196 FAN_PWMOUT
/GP_PWM_OUT1
198 GND
200 SPI_CS0#
202 SPI_CS1#
204 MFG_NC4
206 VCC_5V_SB
208 MFG_NC2
210 MFG_NC3
212 VCC
214 VCC
216 VCC
218 VCC
220 VCC
222 VCC
224 VCC
226 VCC
228 VCC
230 VCC
QEV2m11
Description
PCI Express Channel 3 Input+
PCI Express Channel 3 Input-
Power Ground
PCI Express Channel 2 Input+
PCI Express Channel 2 Input-
Request To Send handshake signal
PCI Express Channel 1 Input+
PCI Express Channel 1 Input-
Clear To Send handshake signal
PCI Express Channel 0 Input+
PCI Express Channel 0 Input-
Power Ground
LPC Interface Address Data 1
General Purpose input/output 1
LPC Interface Address Data 3
General Purpose input/output 3
LPC frame indicator
General Purpose input/output 5
LPC DMA request
General Purpose input/output 7
Output for audio enunciator
General Purpose PWM Output
Fan speed control (PWM)
General Purpose PWM Output
Power Ground
SPI Chip Select 0 Output
SPI Chip Select 1 Output
For manufacturing and debugging purposes
+5VDC Standby ±5%
For manufacturing and debugging purposes
For manufacturing and debugging purposes
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
Power supply +5VDC ±5%
20/49
