Congatec conga-QEVAL/Qseven 2.0 User Manual page 18

Pin Signal Description
HDA_RST# HD Audio Codec Rest
61
/ AC97_RST# AC'97 Codec Reset.
/ I2S_RST# Multiplexed with I2S Codec Reset
HDA_BCLK HD Audio Serial Bit Clock
63
/ AC97_BCLK AC'97 Serial Bit Clock.
/ I2S_CLK Multiplexed with I2S Serial Data Clock
HDA_SDI HD Audio Serial Data Input
65
/ AC97_SDI AC'97 Serial Data Input.
/ I2S_SDI Multiplexed with I2S Serial Data Input
67 HDA_SDO HD Audio Serial Data Output
/ AC97_SDO AC'97 Serial Data Output.
/ I2S_SDO Multiplexed with I2S Serial Data Output.
THRM# Thermal Alarm active low
69
71 THRMTRIP# Thermal Trip indicates an overheating condition
73 GND Power Ground
75 USB_P7- USB Port 7 Differential Pair- . Multiplexed with
/ USB_SSTX0- Superspeed USB transmit differential pair-
77 USB_P7+ USB Port 7 Differential Pair+. Multiplexed with
/ USB_SSTX0+ Superspeed USB transmit differential pair+
79 USB_6_7_OC# Over current detect input for USB port 6 and 7
USB_P5- USB Port 5 Differential Pair-. Multiplexed with
81
/ USB_SSTX1- Superspeed USB transmit differential pair-
USB_P5+ USB Port 5 Differential Pair+. Multiplexed with
83
/ USB_SSTX1+ Superspeed USB transmit differential pair+
USB_2_3_OC# Over current detect input for USB port 2 and 3
85
87 USB_P3- USB Port 3 Differential Pair-
USB_P3+ USB Port 3 Differential Pair+
89
USB_CC USB Client present detect pin
91
USB_P1- USB Port 1 Differential Pair-
93
USB_P1+ USB Port 1 Differential Pair+
95
97 GND Power Ground
eDP0_TX0+ eDP Primary Channel 0+
99
/ LVDS_A0+ LVDS Primary channel 0+
101 eDP0_TX0- eDP Primary channel 0-
/ LVDS_A0- LVDS Primary channel 0-
103 eDP0_TX1+ eDP Primary channel 1+
/ LVDS_A1+ LVDS Primary channel 1+
105 eDP0_TX1- eDP Primary channel 1-
/ LVDS_A1- LVDS Primary channel 1-
107 eDP0_TX2+ eDP Primary channel 2+
/ LVDS_A2+ LVDS Primary channel 2+
Copyright © 2014 congatec AG
Pin Signal
SMB_DAT
62
/ GP1_I2C_DAT
SMB_ALERT#
64
GP0_I2C_CLK
66
GP0_I2C_DAT
68
70 WDTRIG#
72 WDOUT
74 GND
76 USB_P6-
/ USB_SSRX0-
78 USB_P6+
/ USB_SSRX0+
USB_4_5_OC#
80
USB_P4-
82
/ USB_SSRX1-
USB_P4+
84
/ USB_SSRX1+
USB_0_1_OC#
86
USB_P2-
88
USB_P2+
90
USB_ID
92
USB_P0-
94
USB_P0+
96
GND
98
100 eDP1_TX0+
/ LVDS_B0+
102 eDP1_TX0-
/ LVDS_B0-
104 eDP1_TX1+
/ LVDS_B1+
106 eDP1_TX1-
/ LVDS_B1-
108 eDP1_TX2+
/ LVDS_B2+
QEV2m11
Description
SMBus Data line.
Multiplexed with General Purpose I²C bus #1
data line.
SMBus Alert input
General Purpose I2C Bus No 0 clock line
General Purpose I2C Bus No 0 data line
Watchdog trigger signal
Watchdog event indicator
Power Ground
USB Port 6 Differential Pair-. Multiplexed with
Superspeed USB receive differential pair-
USB Port 6 Differential Pair+. Multiplexed with
Superspeed USB receive differential pair+
Over current detect input for USB port 4 and 5
USB Port 4 Differential Pair-. Multiplexed with
Superspeed USB receive differential pair-
USB Port 4 Differential Pair+. Multiplexed with
Superspeed USB receive differential pair+
Over current detect input for USB port 0 and 1
USB Port 2 Differential Pair-
USB Port 2 Differential Pair+
USB ID pin
USB Port 0 Differential Pair-
USB Port 0 Differential Pair+
Power Ground
eDP Secondary channel 0+
LVDS Secondary channel 0+
eDP Secondary channel 0-
LVDS Secondary channel 0-
eDP Secondary channel 1+
LVDS Secondary channel 1+
eDP Secondary channel 1-
LVDS Secondary channel 1-
eDP Secondary channel 2+
LVDS Secondary channel 2+
18/49
