Congatec conga-QEVAL/Qseven 2.0 User Manual page 33

Connector CN9 Pin Description
Pin LVDS Output Pin LVDS Output
GND 17 LVDS_B1+
1
LVDS_A0- GND
2 18
LVDS_A0+ LVDS_B2-
3 19
LVDS_A1- LVDS_B2+
4 20
LVDS_A1+ LVDS_B_CLK-
5 21
LVDS_A2- LVDS_B_CLK+
6 22
7 LVDS_A2+ LVDS_B3-
23
GND LVDS_B3+
8 24
LVDS_A_CLK- GND
9 25
LVDS_A_CLK+ LVDS_DID_DAT
10 26
LVDS_A3- 27 LVDS_PPEN
11
LVDS_A3+ LVDS_DID_CLK
12 28
LVDS_B0- VDD_LCD (750mA Fuse)
13 29
LVDS_B0+ VDD_LCD (750mA Fuse)
14 30
GND VDD_LCD (750mA Fuse)
15 31
LVDS_B1- GND
16 32
Connector Type
CN9: JAE FI-X30SSL-HF, 32 pin, single row, 1mm pitch spacing (compatible with JILI30).
With Jumper X50, you can set up the polarity of the backlight enable signal 'LVDS_BLEN' from the Qseven
Configuration
Jumper X50
1 - 2 Backlight enable HIGH active (default)
2 - 3 Backlight enable LOW active
Connector Type
X50: 2.54mm grid Jumper.
Copyright © 2014 congatec AG
LVDS Connector
(CN9)
Backlight Polarity
Config
(X50)
1 2 3
QEV2m11
module.
®
33/49
