Additional Features

6.1

6.1.1

The conga-QA3/QA3E revision B.x and later offer an onboard camera interface via the feature connector. The interface supports up to two

independent cameras - four data lanes for the first camera and one data lane for the second camera. Each lane operates at up to 1 GT/s

depending on the camera resolution. It also supports up to 24 MP image capture @ 15fps, full HD 1080p60.

The MIPI-CSI-2 interfaces follow the CSI-2 specification as defined by the MIPI Alliance and support YUV420, YUV422, RGB444, RGB555,

RGB565, RGB888, JPEG and RAW 8/10/12/14. The MIPI interface is also compliant with the SGET Camera Feature Specification.

For the signal descriptions, see table 25 "Onboard Camera Interface Signal Descriptions".

Note

The conga-QA3/QA3E celeron variants do not support MIPI-CSI 2.0.

6.1.2

The conga-QA3/QA3E offers an optional eMMC 4.5 flash onboard the Intel Atom variants, with up to 32 GB capacity. The conga-QA3/QA3E

celeron variants do not offer eMMC.

6.2

The conga-QA3/QA3E is equipped with a Texas Instruments Tiva™ TM4E1231H6ZRBI microcontroller. This onboard microcontroller plays an

important role for most of the congatec BIOS features. It fully isolates some of the embedded features such as system monitoring or the I²C

bus from the x86 core architecture, which results in higher embedded feature performance and more reliability, even when the x86 processor

is in a low power mode.

QA30_QA3Em11

30/91
