Technical Support
congatec AG technicians and engineers are committed to providing the best possible technical support for our customers so that our products
can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation, utilities and
drivers, which have been made available to assist you. If you still require assistance after visiting our website then contact our technical support
department by email at support@congatec.com
Terminology
Term
PCI Express (PCIe)
PCI Express Lane
x1, x2, x4, x16
PCI Express Mini Card
MMCplus
SDIO card
USB
SATA
HDA
S/PDIF
HDMI
TMDS
DVI
LPC
I²C Bus
SM Bus
CAN
SPI
GBE
LVDS
DDC
N.C.
N.A.
T.B.D.
Copyright © 2014 congatec AG
Description
Peripheral Component Interface Express – next-generation high speed Serialized I/O bus
One PCI Express Lane is a set of 4 signals that contains two differential lines for
Transmitter and two differential lines for Receiver. Clocking information is embedded into the data stream.
x1 refers to one PCI Express Lane of basic bandwidth; x2 to a collection of two PCI Express Lanes; etc.. Also referred to as x1, x2, x4 or x16 link.
PCI Express Mini Card add-in card is a small size unique form factor optimized for mobile computing platforms.
MMCplus was defined for first time in MMC System Specification v4.0. MMCplus is backward compatible with MMC. MMCplus has 13 pins.
SDIO (Secure Digital Input Output) is a non-volatile memory card format developed for use in portable devices.
Universal Serial Bus
Serial AT Attachment: serial-interface standard for hard disks
High Definition Audio
S/PDIF (Sony/Philips Digital Interconnect Format) specifies a Data Link Layer protocol and choice of Physical Layer specifications for carrying digital
audio signals between devices and stereo components.
High Definition Multimedia Interface. HDMI supports standard, enhanced, or high-definition video, plus multi-channel digital audio on a single cable.
Transition Minimized Differential Signaling. TMDS is a signaling interface defined by Silicon Image that is used for DVI and HDMI.
Digital Visual Interface is a video interface standard developed by the Digital Display Working Group (DDWG).
Low Pin-Count: a low speed interface used for peripheral circuits such as Super I/O controllers, which typically combine legacy device support into a
single IC.
Inter-Integrated Circuit Bus: is a simple two-wire bus with a software-defined protocol that was developed to provide the communications link
between integrated circuits in a system.
System Management Bus: is a popular derivative of the I²C-bus.
Controller Area Network
Serial Peripheral Interface
Gigabit Ethernet
Low-Voltage Differential Signaling
Display Data Channel is an I²C bus interface between a display and a graphics adapter.
Not connected
Not available
To be determined
