START-UP AND OPERATION

Merchandiser Start-Up
• Remote Units: Case is hard-wired. When power is
supplied, case will power-up.
• Self-Contained: Main power switch and
temperature controller is located at case rear,
lower right. See illustrations below-left and right.
• Self-Contained: Depending upon model, switch
cover may be provided to protect controller and
switch. See illustration at lower-left.
• Turn on the lights. Whether Remote or
Self-Contained, light switch is located on inside of
case at top right, from case rear. See illustration at
top right.
•
All lights should come on at same time. First time
lighting may require a short warm up period for the
bulbs. Slightly dim or a flickering of new bulbs is
normal.
• The lighting is wired in series so all lights must be
plugged in or receptacles capped for case lights
to turn on.
Switch Cover
Note: Certain Models May Have a Switch Cover.
If So, Simply Slide To The Left To Access Controls
Temperature
Controller
12
Cap
Plug
Receptacle
Main Power Switch
