STANDARD NIGHT AIR CURTAIN LOCATION FOR MODEL HMO5136R.4716
NOTE: BELOW ILLUSTRATION APPLIES
TO MODEL HMO5136R.4716 ONLY.
View of Night Air Curtain
(Topside / Attached)
Night Air Curtain
Retraction Handle
Night Air Curtain
Retraction Magnets Attachment
Points (Along Plate Outside
Acrylic Air Deflector)
Acrylic
Air Deflector
17
