Structural Concepts HARMONY HMO7536R User Manual page 20

SECURITY GRID OPERATING INSTRUCTIONS (OPTIONAL) - PAGE #2 of 2
Securing Security Grid Into Place and Locking
1. After leaning the Security Grid back against the two Security Brackets, slide the Padlocks
through the Security Grid and the Security Brackets.
2. Securely lock the Padlocks (one Key fits both Padlocks).
Removing and Storing Security Grid and Locks
1. Unlock and remove Padlocks. Lean Security Grid forward. Lift upward and out of Baffle
Airflow Slots. Tabs fit into (and slide out of) baffle slots as in other units. See next page
tab and baffle slot locations and illustrations.
2. Store Security Grid, Padlocks and Keys in a secure location to prevent theft or damage.
Security
Security
Bracket
Grid
Padlock
Security
Grid
•
•
Security
Grid
20
Enlarged View (At Left)
Enlarged View (at left) shows Padlock
through Security Grid and Security
Bracket.
There are two Security Brackets for
each Security Gred.
NOTE:
ILLUSTRATIONS
MAY NOT
EXACTLY
REFLECT EVERY
PARTICULAR
CASE'S
FEATURES
