INSTALLATION, CONTINUED
Case Rear
Field Wiring Electrical
Connections
5. Electrical Connections (Certain Remote Cases)
Field wiring connection / electrical access location is at
customer-left side of case.
• Single phase leads are provided.
6. Evaporator Fan Area
• Illustration below shows front of case with decking
removed.
• See Preventive Maintenance section in this manual
for guidelines on cleaning this area.
Fan Shroud
Fan Blade
Drain
