MAINTENANCE FUNDAMENTALS, CONT'D - UPPER SECTION WITH ACRYLIC BINS
5. Upper Section With Acrylic Bins
• Note: Illustration shown reflects model
HMO5136R.7121 (and possibly other models).
• Illustration is not applicable to all models in this
manual.
• Acrylic bin doors may be raised and lowered by
accessing the knobs (as shown below).
• See CLEANING SCHEDULE (PERFORMED
BY STORE PERSONNEL) section in manual for
cleaning specifics.
6. Removable Acrylic Bin Door Assembly
• Acrylic bin door assembly is entirely removable
from upper section of case.
•
Simply rotate keys (at upper left/right of assembly)
and lower the levers holding it intact. Lift assembly
up and off the pins that are holding lower acrylic bin
door assembly bracket to deck.
•
See CLEANING SCHEDULE (TO BE
PERFORMED BY STORE PERSONNEL) section
in manual for cleaning specifics.
• Important! Store keys in safe but accessible
location for ready access.
Both Keys Must Be
Turned To Lower Levers
And Remove Acrylic Bin
15
Door Assembly
