Structural Concepts HARMONY HMO7536R User Manual page 9

INSTALLATION, CONTINUED
7. Honeycomb Air Diffuser
• Honeycomb is located in discharge air duct.
• From inside lower refrigerated area, locate the
two most forward screws which secure the lower
light & discharge panel.
•
Remove the two most forward screws; panel
must hang down supported by the rear screws.
Do not force panel lower.
• See MAINTENANCE FUNDAMENTALS -
HONEYCOMB AIR DIFFUSER section in this
manual for complete instructions on removal
and installation of honeycomb.
Honeycomb
Honeycomb
Retainer
9
