Siemens VDO modulcockpit II Product Manual page 99

Technical Product Manual
VDO modulcockpit II
5. Testing Instructions
5.9 List:
Technical Data
Voltmeters
Voltmeter (8V-16V)
Indication
Tolerance
Pointer deflection angle
Voltmeter (8V-16V)
Indication
Tolerance
Pointer deflection angle
Voltmeter (18V-32V)
Indication
Tolerance
Pointer deflection angle
TU00-0740-0000002
12V
8V 10V 12V
± 0.85V ± 0.6V ± 0.5V
0 16.8 44.1
12V
8V 10V 12V
± 0.85V ± 0.6V ± 0.5V
0 17 40
24V
18V 21V 24V
± 1.5V ± 1.2V
0 13.1 33.6
0904
Single Instrument Modules (Ke)
332-305-980-003C
14V 16V
± 0.5V ± 0.75V
70.8 87.6
332-305-980-001C
14V 16V
± 0.5V ± 0.75V
71 90
332-305-980-004C
28V 32V
±1.5V
66.4 88
phase-out (available as long as stock)
5 - 22
