Technical Product Manual
VDO modulcockpit II
2.
Components
2.1
2 Unit Instrument Module, Vertical
(Ke + Ke)
Single instrument module
+ single instrument module
Single instrument module:
fuel level gauge, version tubulare type sensor,
only for position
Pos.
Designation
page 2 - 2
1
Housing assy
10
Single instrument module
20
Circuit board assy 12 V
Circuit board assy 24 V
30
Shield
31
Spring washer 4 DIN 137
32
Hex nut M4 ISO 4032 (DIN 934)
33
Washer 3.2 DIN 433
34
Screw, 43 mm
35
Bracket
36
Screw, 25 mm
40
Base bulb 12 V 1.2 W
Base bulb 24 V 1.2 W
41
Connector socket
43
Housing, 5-fold
TU00-0740-0000002
I
.
(Ke)
Quantity
0704
Part No.
1x
X11-395-000-029
2x
(see chapter 2.5)
1x
X11-395-000-056
1x
X11-395-000-057
2x
X11-395-000-008
2x
4-027-003-1162
4x
4-077-003-1161
2x
4-033-005-1162
2x
21-974-018-1141
2x
X11-395-000-009
4x
X11-395-000-016
2x
92-171-005
2x
92-171-003
5x
X11-000-014-005
1x
X11-000-014-002
I
II
2 - 5
