Siemens VDO modulcockpit II Product Manual page 32

Technical Product Manual
VDO modulcockpit II
2. Components
2.6 Single Instrument Modules (EBZ)
50
43
41
Pos. Designation
1 Housing assy
23 Circuit board assy 12 V
Circuit board assy 24 V
32 Hex nut M4 ISO 4032 (DIN 934)
33 Washer 3.2 DIN 433
34 Screw, 43 mm
35 Bracket
36 Screw, 25 mm
37 Screw, 13 mm
41 Connector socket
43 Housing, 5-fold
50 Blind cover, black
TU00-0740-0000002
23
36
37
(EBZ)
(EBZ)
1
33
Clip
Part No. 81-045-109
34
(according to requirement)
35
32
Preselected instruments see chapter 4.4
Other changes see chapter 2.1
0704
Quantity Part No.
1x X11-395-000-029
1x X11-395-000-044
1x X11-395-000-045
2x 4-077-003-1161
3x 4-033-005-1162
2x 21-974-018-1141
2x X11-395-000-009
4x X11-395-000-016
1x 4-109-003-1162
5x X11-000-014-005
1x X11-000-014-002
1x X11-395-000-014
2 - 22
