Siemens VDO modulcockpit II Product Manual page 22

Technical Product Manual
VDO modulcockpit II
2. Components
2.3 4 Unit Instrument Module
(4x Ke)
4x single instrument module
Single instrument module:
fuel level gauge, version
tubular type sensor, only
I
for position .
Pos.
Designation
Page 2 - 2
2 Housing assy
10 Single instrument module (Ke)
26 Circuit board assy 12 V
Circuit board assy 24 V
30 Shield
31 Spring washer 4 DIN 137
32 Hex nut M4 ISO 4032 (DIN 934)
33 Washer 3.2 DIN 433
34 Screw, 43 mm
35 Bracket
36 Screw, 25 mm
37 Screw, 14 mm
40 Base bulb 12 V 1.2 W
Base bulb 24 V 1.2 W
41 Connector socket
44 Housing, 7-fold
TU00-0740-0000002
I
II
Quantity
0704
Part No.
1x X11-395-000-028
4x (see chapter 2.5)
1x X11-395-000-054
1x X11-395-000-055
4x X11-395-000-008
4x 4-027-003-1162
6x 4-077-003-1161
2x 4-033-005-1162
2x 21-974-018-1141
2x X11-395-000-009
4x X11-395-000-016
3x X11-395-000-015
4x 92-171-005
4x 92-171-003
7x X11-000-014-005
1x X11-000-014-003
III
IV
2 - 12
