SITRANS F
Electromagnetic flowmeters
SITRANS FM MAG6000I/6000I Ex
Operating Instructions
7ME693 (MAG6000I)
07/2024
A5E02083319-AK
Introduction
Safety notes
Description
Installing/Mounting
Connecting
Commissioning
Functions
Alarm, error, and system
messages
Service and maintenance
Troubleshooting/FAQs
Technical specifications
Spare parts/Accessories
Product documentation
and support
Menu diagrams
Factory settings
1
2
3
4
5
6
7
8
9
10
11
12
A
B
C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SITRANS F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SITRANS F

Summary of Contents for Siemens SITRANS F

  • Page 1 Introduction Safety notes Description SITRANS F Installing/Mounting Electromagnetic flowmeters SITRANS FM MAG6000I/6000I Ex Connecting Commissioning Operating Instructions Functions Alarm, error, and system messages Service and maintenance Troubleshooting/FAQs Technical specifications Spare parts/Accessories Product documentation and support Menu diagrams 7ME693 (MAG6000I) Factory settings...

  • Page 2: Qualified Personnel

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction ............................7 Purpose of this documentation .................... 7 Document history ........................ 7 Designated use ........................8 Industrial use note ....................... 8 Checking the consignment....................8 Items supplied ........................9 Cybersecurity information ....................9 Transportation and storage ....................10 Notes on warranty ......................
  • Page 4 Table of contents Connection of sensor and transmitter in remote version ............. 34 Wiring in hazardous area....................36 Connection of bus communication add-on modules ............38 Reassembling the device ....................38 Commissioning ............................ 39 Local user interface......................39 Menu structure ........................41 Changing password ......................
  • Page 5 Table of contents 11.7 Certificates and approvals....................73 11.7.1 Hazardous area approvals and certificates................73 11.7.2 Electrical specifications ...................... 77 11.7.3 Specific conditions of use ....................80 Spare parts/Accessories ........................83 12.1 Ordering of spare parts ...................... 83 12.2 Accessories ........................84 12.3 Spare parts ........................
  • Page 6 Table of contents SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 7: Introduction

    "?". The unit can still be changed. – Improved minimum supply voltage for current out‐ put to 12 V. • Document revision identification changed according to new SIEMENS standard 09/2012 • Enhanced current output function 4.07 X06 •...

  • Page 8: Designated Use

    Introduction 1.5 Checking the consignment Edition Remarks HW version SW version 12/2011 4.07 X06 • Updated ATEX approval • General update 03/2011 4.06 X06 • First edition • Transmitter upgrade information included Designated use Use the device in accordance with the information on the nameplate and in the Technical specifications (Page 65).

  • Page 9: Items Supplied

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...

  • Page 10: Transportation And Storage

    The content reflects the technical status at the time of publishing. Siemens reserves the right to make technical changes in the course of further development.

  • Page 11: Safety Notes

    Safety notes This device left the factory in good working condition. In order to maintain this status and to ensure safe operation of the device, observe these instructions and all the specifications relevant to safety. Observe the information and symbols on the device. Do not remove any information or symbols from the device.

  • Page 12: Laws And Directives

    Material compatibility Siemens Flow Instruments can provide assistance with the selection of wetted sensor parts. However, the full responsibility for the selection rests with the customer and Siemens Flow Instruments can take no responsibility for any failure due to material incompatibility.

  • Page 13: Improper Device Modifications

    Safety notes 2.4 Use in hazardous areas Explosive atmospheres direc‐ Directive of the European Parliament and the Council on the har‐ tive ATEX monisation of the laws of the Member States relating to equip‐ 2014/34/EU ment and protective systems intended for use in potentially ex‐ plosive atmospheres Pressure equipment direc‐...
  • Page 14 Safety notes 2.4 Use in hazardous areas WARNING Use in hazardous area Risk of explosion. • Only use equipment that is approved for use in the intended hazardous area and labeled accordingly. • Do not use devices that have been operated outside the conditions specified for hazardous areas.
  • Page 15 Safety notes 2.4 Use in hazardous areas WARNING Use interface sealing gasket in dust explosion hazardous area When the equipment is installed in dust explosion hazardous area the cable entry devices shall be fitted with interface sealing gasket. WARNING Opening device in energized state Risk of explosion in hazardous areas •...
  • Page 16 Safety notes 2.4 Use in hazardous areas SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 17: Description

    Description Applications The pulsed DC-powered magnetic flowmeters are suitable for measuring the flow of almost all electrically conductive liquids, pastes, and slurries with max. 40% solids. The main applications can be found in the following sectors: • Water and waste water •...

  • Page 18: Design

    Description 3.3 Design Ex-transmitter: • HART • PROFIBUS PA • Foundation Fieldbus H1 Design The SITRANS FM MAG 6000I / MAG 6000I Ex de transmitter is designed for demands in the process industry. The robust cast aluminum housing provides superb protection, even in the most harsh industrial environments.

  • Page 19: Nameplate Layout

    Description 3.4 Nameplate layout Nameplate layout Inspection 1. Check for mechanical damage due to possible improper handling during shipment. All claims for damage are to be made promptly to the carrier. 2. Make sure the scope of delivery, and the information on the namelate corresponds to the ordering information Identification ①...

  • Page 20: Features

    3.6 Principle of operation Features • SENSORPROM memory unit ® – All SITRANS F M electromagnetic flowmeters feature a unique SENSORPROM memory ® unit which stores sensor calibration data as well as transmitter settings for the lifetime of the product. – At commissioning the flowmeter commences measurement without any initial programming.
  • Page 21 Description 3.6 Principle of operation = L x B x v • Ui = Induced voltage • L = Conductor length = Inner pipe diameter = k • B = Magnetic field strength = k • v = Velocity of conductor (media) •...
  • Page 22 Description 3.6 Principle of operation SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 23: Installing/Mounting

    This chapter describes how to install the flowmeter in the compact version as well as in the remote version. SITRANS F flowmeters with minimum IP67/Type 4X enclosure rating are suitable for indoor and outdoor installations. All sensors have an associated SENSORPROM ®...

  • Page 24: Compact Installation

    Installing/Mounting 4.3 Compact installation Vibrations Figure 4-1 Avoid strong vibrations In installation with strong vibrations remote installation of the transmitter is recommended. Compact installation The flowmeter is delivered with default factory settings and start measuring the flow rate after power-up. The SENSORPROM is factory-mounted in the transmitter.

  • Page 25: Remote Installation

    Installing/Mounting 4.4 Remote installation Remote installation For remote versions the SENSORPROM has to be removed from the sensor terminal box and ® mounted in the remote transmitter. Figure 4-3 Remote installation Cable length and type (as described in Cable requirements (Page 72)) must be used. For installation conditions for sensors, see respective sensor operating instructions.
  • Page 26 Installing/Mounting 4.4 Remote installation 3. Mount SENSORPROM in remote transmitter. ® 4. Fit M20 or ½" NPT cable glands on sensor terminal box. 5. Fit and connect electrode and coil cables as described in Connecting (Page 31). Note Unscreened cable ends must be kept as short as possible. Electrode cable and coil cable must be kept separate to prevent interference.

  • Page 27: Wall Mounting Using Standard Mounting Plate

    Installing/Mounting 4.4 Remote installation 4.4.1 Wall mounting using standard mounting plate 1. Fit the mounting plate on the transmitter using the mounting material provided 2. Mount transmitter with mounting plate on the wall. Figure 4-4 Standard mounting plate For details on mounting plate, see Dimensions and weight (Page 67). Note The standard mounting plate is only suitable for wall mounting.

  • Page 28: Pipe Mounting

    Installing/Mounting 4.4 Remote installation Pipe mounting 1. Mount the assembly bracket on the pipe using the fastening brackets 2. Fasten the transmitter with the two screws provided. Pipe mounting with assembly bracket Wall mounting 1. Fasten the assembly bracket to the back of the transmitter 2.

  • Page 29: Connecting

    Connecting This chapter describes how to wire up the device without bus communication. In order to wire up devices with communication modules, e.g. HART, Profibus PA or DP, Foundation Fieldbus, DeviceNet or MODBUS, refer to the Operating Instructions for relevant add-on module.

  • Page 30: Safety Precautions

    Connecting 5.1 Safety precautions Safety precautions WARNING Mains supply from building installation Overvoltage category II A fused (max. 16 A) circuit breaker must be installed in close proximity to the equipment and within easy reach of the operator. It must be marked as the disconnecting device for the equipment.

  • Page 31: Electrical Connection

    Connecting 5.2 Electrical connection Electrical connection SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...
  • Page 32 Connecting 5.2 Electrical connection Note Min. 4 mm is only required for ATEX 2 GD and FM/CSA Class I, Zone 1/21 installations. Note Terminals 81 and 84 are only to be connected if special electrode cable with double screening is used, e.g. when empty pipe function or long cables are used. Note Special cable with individual wire shields (shown as dotted lines) are only required when using empty pipe function or long cables.
  • Page 33 Connecting 5.2 Electrical connection Active/passive current output Active/Passive Factory default Active MAG6000I standard version Passive MAG6000I Ex version Note For Ex versions active or passive current output is preselected at ordering and cannot be changed. Non-Ex versions can be connected as either active or passive. Note The factory default setting for the current output is marked by an "X"...

  • Page 34: Connection Of Sensor And Transmitter In Remote Version

    Connecting 5.3 Connection of sensor and transmitter in remote version Figure 5-2 Example of label inside the lid Connection of sensor and transmitter in remote version The following contains a short description of how to connect the sensor to the transmitter SITRANS FM MAG6000I. For more information refer to the Operating Instructions for the respective sensor.
  • Page 35 Connecting 5.3 Connection of sensor and transmitter in remote version 1. Relocate SENSORPROM memory unit from sensor to transmitter terminal block. ® 2. Fit coil and electrode cables through cable glands in sensor terminal box. 3. Connect signal and coil cables to transmitter as follows: SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 36: Wiring In Hazardous Area

    Connecting 5.4 Wiring in hazardous area • Remove cover for connection board. • Remove protection plate for connectors • Remove the two connectors. • Mount the two cables through the two cable glands and mount connectors on coil and electrode cables. •...
  • Page 37 Connecting 5.4 Wiring in hazardous area Current output in passive and active modes Non Ex Current output passive with HART Isolator + Loop - Loop Current output passive Barrier / Isolator + Loop + Loop smin smin = Σ R = Σ R <...

  • Page 38: Connection Of Bus Communication Add-On Modules

    91-97. For more information Refer to the relevant BUS communication Quick Start or Operating Instructions available at the SITRANS F literature CD or on the internet, at: www.siemens.com/flowdocumentation (www.siemens.com/flowdocumentation) Reassembling the device Ensure that the two screws (20 TORX) are tightened properly for correct assembly and proper ground connection.

  • Page 39: Commissioning

    Commissioning In this chapter it is described how to commission the device via the local user interface (LUI). The display is described in details in section Local user interface (Page 39). Furthermore, the following functions are described in details: • Changing password (Page 41) •...
  • Page 40 Commissioning 6.1 Local user interface Figure 6-2 Capacitive touch keypad Note Isolate the device from power when removing the glass lid If the glass lid is rotated during operation, the capacitive touch keypad automatically calibrates to align the distance from lid to keypad. To avoid any unintended programming during this calibration procedure, it is recommended to always isolate the device from power before removing the glass lid and until it is properly fixed to the device again.

  • Page 41: Menu Structure

    Commissioning 6.3 Changing password CHANGE KEY With this key settings or numerical values are changed. SELECT KEY With this key figures to be changed are selected. LOCK/UNLOCK KEY This key enables the operator to change settings and it gives access to submenus. Menu structure The menu is built up of two parts.

  • Page 42: Changing Basic Settings

    Commissioning 6.4 Changing basic settings 6. Press lock/unlock key to confirm new password. 7. Press top up key two times to exit setup mode. The factory-set password is 1000, but it can be changed to any value between 1000 and 9999. Factory setting of password can be re-established as follows: 1.
  • Page 43 Commissioning 6.4 Changing basic settings Note 2 is visible only when chosen as digital input. Change basic settings as follows: 1. Press top up key for 2 sec. 2. Enter password. 3. Use forward key to reach basic settings menu. 4. Press lock/unlock key to unlock settings.
  • Page 44 Commissioning 6.4 Changing basic settings 9. Repeat steps 5-8 to change other settings. 10.Press top up key two times to exit setup mode. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...
  • Page 45 Commissioning 6.4 Changing basic settings Decimal point can be positioned and units set individually for flow rate in totalizer 1 and totalizer 2. Changing decimal point position 1. Enter the respective totalizer menu. 2. Use select key to position cursor below decimal point. 3.

  • Page 46: Changing Operator Menu Setup

    Commissioning 6.5 Changing operator menu setup Changing units Note Menus disabled on MAG 5000/6000 CT Due to legal requirements, some parameters are disabled on MAG 5000/6000 CT. Only available units are m /h and m 1. Use select key to position cursor below unit. 2.

  • Page 47: Changing Language

    Commissioning 6.6 Changing language 7. Use change key to select desired setting. 8. Press lock/unlock key to confirm new setting. 9. Repeat steps 1-8 for each requested menu. Showing/hiding menus in operator menu 1. Use forward key to reach requested menu. 2.
  • Page 48 Commissioning 6.6 Changing language SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 49: Functions

    Functions Introduction This chapter describes the various menus of the transmitter in details. The menu diagrams are shown in appendix Menu diagrams (Page 89). Output settings Three outputs are available: • Current output (range and time constant); terminals 31 and 32. •...

  • Page 50: Digital Output

    Functions 7.3 External input Digital output Digital output can be used to configure various settings: • Pulse (volume/pulse, pulse output, pulse width, pulse polarity, and time constant), see Pulse menu diagram (Page 94). • Frequency (frequency output, max frequency, and time constant), see Frequency menu diagram (Page 95).

  • Page 51: Sensor Characteristics

    Functions 7.6 Service mode Sensor characteristics The sensor characteristics menu shows: • If a SENSORPROM is installed or not ® • Suppress error P 40 (SENSORPROM not installed) ® • Sensor size • Calibration factor • Correction factor • Excitation See Sensor characteristics (Page 98). Note If a SENSORPROM is not installed, check the sensor characteristics to see if they match the product label and the previous customer settings.
  • Page 52 Functions 7.6 Service mode The forced control is stopped and all previous settings are reinitialized the moment the service mode is left by pressing top up key SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 53: Alarm, Error, And System Messages

    Alarm, error, and system messages Diagnostics Error system Transmitter system is equipped with an error and status log system with 4 groups of information. (I) Information - system will continue to measure as normal, relay and current outputs will not be affected. (W) Warning - system will continue to measure, but an event that may cause a system malfunction and require operator attention has occurred.
  • Page 54 Alarm, error, and system messages 8.1 Diagnostics Acceptance levels The following three acceptance levels are selectable. • Fatal error: Only fatal errors are registered as errors • Permanent error: Permanent and fatal errors are registered as errors • Warning (Default value): Warnings, permanent and fatal errors are registered as errors Error information is displayed in title and subtitle lines, see display layout (Page 39).

  • Page 55: List Of Error Numbers

    Alarm, error, and system messages 8.2 List of error numbers List of error numbers Error Error text Comment Output Input Remedy text status status I1 - Power on       Device powered on Active Active I2 - Add-on module    ...
  • Page 56 Zero Inactive ® product ID. The SENSORPROM unit is from another type of prod‐ ® uct SITRANS F C, SITRANS F US etc. F63 - SENSORPROM®       Replace It is not possible to read from the SENSORPROM ®...

  • Page 57: Service And Maintenance

    • Ambient conditions • Seal integrity of the process connections, cable entries, and cover screws • Reliability of power supply, lightning protection, and grounds Note Siemens defines flow sensors as non-repairable products. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 58: Disposal

    To return a product to Siemens, see Returns to Siemens (www.siemens.com/returns-to- siemens). Contact your Siemens representative to clarify if a product is repairable, and how to return it. They can also help with quick repair processing, a repair cost estimate, or a repair report/ cause of failure report.
  • Page 59 Service and maintenance 9.3 Disposal NOTICE Data misuse resulting from non-secure deletion of data Incomplete or non-secure deletion of data from data memories can result in data misuse by third parties. For this reason, ensure secure deletion of data from all storage media used before disposing of the product.
  • Page 60 Service and maintenance 9.3 Disposal SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 61: Troubleshooting/Faqs

    Troubleshooting/FAQs 10.1 Troubleshooting guide Symptom Output sig‐ Error code Cause Remedy nals Empty display Minimum   1. No power supply Power supply Check MAG 5000/6000/6000 I for ben‐ ded pins on the connector 2. MAG 5000/6000/6000 I de‐ Replace MAG 5000/6000/6000 I fective No flow signal Minimum...

  • Page 62: Transmitter Check List

    Troubleshooting/FAQs 10.2 Transmitter check list Symptom Output sig‐ Error code Cause Remedy nals Measuring error Undefined   Incorrect installation Check installation No SENSORPROM ® unit Install SENSORPROM ® unit CT SENSORPROM unit Replace SENSORPROM unit or reset ® ® SENSORPROM unit with MAG CT trans‐ ®...
  • Page 63 Troubleshooting/FAQs 10.2 Transmitter check list Power on transmitter 1.2.1 Transmitter OK Check application Check installation/sensor/earthing connec‐ tion etc. 1.2.2 Check cables/connections OK ⇒ 1.2.1 Not OK ⇒ correct fault Check cables/connections OK ⇒ 2.1 Not OK ⇒ Correct fault Output readings OK? Yes ⇒...
  • Page 64 Troubleshooting/FAQs 10.2 Transmitter check list SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 65: Technical Specifications

    Technical specifications 11.1 Technical specifications Technical specifications for MAG6000I standard and Ex version Mode of operation and design Measuring principle Electromagnetic with pulsed constant field Empty pipe Detection of empty pipe (special cable required in remote mounted installation) Excitation frequency Depends on sensor size Electrode input impedance >...
  • Page 66 Technical specifications 11.1 Technical specifications Technical specifications for MAG6000I standard and Ex version Rated operation conditions Ambient temperature   Operation   -20 to +60 °C (-13 to +140 °F) • MAG 6000I -20 to +60 °C (-13 to +140 °F) • MAG 6000I Ex Storage -40 to +70 °C (-40 to +158 °F)

  • Page 67: Dimensions And Weight

    Technical specifications 11.2 Dimensions and weight Technical specifications for MAG6000I standard and Ex version Cable entries (remote installation) MAG6000I: 2 x M25 (for supply/output) and 2 x M16 (for sensor connection) or 2 x ½" NPT (for supply/output) and 2 x M16 (for sensor connection) MAG6000I Ex: 2 x M20 (for supply/output) and 2 x M16 (for sensor connection)

  • Page 68: Accuracy

    Technical specifications 11.3 Accuracy 11.3 Accuracy For accuracy reference conditions, see below. [±% E] V: Flow velocity E: Meter uncertainty as a percentage of measured value v ≥ 0.1 m/s (0.3 ft/s) --> E: ± 0.2 ± 1 mm/s * v < 0.1 m/s (0.3 ft/s) --> E: ± (0.125/v) % of measured value * * MAG 5100 W with DN 350 ...

  • Page 69: Output Characteristics

    Technical specifications 11.4 Output characteristics Effect of supply voltage < 0.005% of measuring value on 1% change Repeatability ± 0.1% of actual flow for V ≥ 0.5 m/s (1.5 ft/s) and con‐ ductivity ≥ 10 μS/cm Additions in the event of deviations from reference conditions 11.4 Output characteristics Current output...

  • Page 70: Relay Output

    Technical specifications 11.4 Output characteristics Relay output Bidirectional mode Unidirectional mode Power down Active Error relay output Bidirectional mode Unidirectional mode No error Error Limit switch (can be used as direction switch) 1 set point 2 set points Passive Digital output Passive Digital output SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 71: Cable Data

    Technical specifications 11.5 Cable data Batch on digital output Unidirectional mode (forward flow only) Totalizer lap Batch on relay output Unidirectional mode (forward flow only) Hold Batch 11.5 Cable data Description Electrode or coil cable (standard) Electrode cable, double shielded (for empty pipe detection or low conductivity fluids) Cable kit with standard coil cable and electrode cable double shielded (also available as low noise cable for MAG 1100 sensor)

  • Page 72: Technical Data

    Technical specifications 11.6 Cable requirements Technical data     Standard cable Double-shielded cable (electrode/coil) (electrode) Basic data No. of conductors Sqr. area 1.5 mm 0.25 mm Screen Double Color code Brown, blue, black Brown, blue, black Outside color Grey Grey Ext. diameter 7.8 mm 8.1 mm Conductor...

  • Page 73: Certificates And Approvals

    Technical specifications 11.7 Certificates and approvals 11.7 Certificates and approvals 11.7.1 Hazardous area approvals and certificates The device is approved for use in hazardous areas and has the approvals listed below. Special conditions for safe installation and operation specified by each approval authority are included in the relevant certificate.
  • Page 74 Technical specifications 11.7 Certificates and approvals Table 11-1 SITRANS FM MAG6000I Ex Certification Ex marking ATEX/UKEX/IECEx CSANe 24 ATEX1108X IECEx CSAE 24.0018X CSAE 24 UKEX1033X II 2 (1) GD    Ex db eb ia [ia Ga] IIC T6 Gb Ex db eb ia [ia IIC Ga] IIB T6 Gb Ex tb [ia Da] IIIC T85°C Db Ta: -20°C to +60°C Note:...
  • Page 75 Technical specifications 11.7 Certificates and approvals Compact transmitter version with SITRANS FM MAG3100 sensor Table 11-3 SITRANS FM MAG6000I Ex DN15 to DN300 MAG3100 “7ME6310” / MAG3100HT “7ME6320” / MAG3100P “7ME6340” Certification Ex marking ATEX/UKEX/IECEx Transmitter CSANe 24ATEX1108X CSAE 24UKEX1033X IECEx CSAE 24.0018X Electromagnetic flow sensor CSANe 24ATEX1107X CSAE 24UKEX1032X...
  • Page 76 Technical specifications 11.7 Certificates and approvals Table 11-4 SITRANS FM MAG6000I Ex DN350 to DN2000 MAG3100 “7ME6310” Certification Ex marking ATEX/UKEX/IECEx Transmitter CSANe 24ATEX1108X CSAE 24UKEX1033X IECEx CSAE 24.0018X Electromagnetic flow sensor CSANe 24ATEX1107X CSAE 24UKEX1032X IECEx CSAE 24.0017X II 2 (1) G D Ex db eb ia [ia Ga] IIC T6…T3 Gb Ex db eb ia [ia IIC Ga] IIB T6…T3 Gb Ex ia tb [ia Da] IIIC T85°C…T160°C Db...

  • Page 77: Electrical Specifications

    Technical specifications 11.7 Certificates and approvals Table 11-5 SITRANS FM MAG6000I Ex DN2 to DN100 MAG1100 “7ME6110” / MAG1100F “7ME6140” Certification Ex marking ATEX/UKEX Transmitter CSANe 24ATEX1108X CSAE 24UKEX1033X Electromagnetic flow sensor Sira 07ATEX3181X CSAE 22UKEX1308X II 2 (1) GD Ex db eb ia [ia IIC Ga] IIB T6…T3 Gb Ex tb [ia Da] IIIC T85°C…T198°C Db 11.7.2 Electrical specifications...
  • Page 78 Technical specifications 11.7 Certificates and approvals Connection 7ME6930-2BA42-1cAd 7ME6930-2BA52-1cAd Terminals L & N = 20…27 V DC = 115…230 V AC Supply = 30 V DC = 253 V AC 25 VA   Intrinsic safety electrical parameters “Ex ia” Terminals 31 & 32 Passive mode configuration (I-OUT PASSIVE) Current Output (I-OUT)  : 30 V ;...
  • Page 79 Technical specifications 11.7 Certificates and approvals Connection 7ME63x0-xxxxx-xDxx 7ME63x0-xxxxx-xExx Terminals L & N = 20…27 V DC = 115…230 V AC Supply = 30 V DC = 253 V AC 25 VA   Intrinsic safety electrical parameters “Ex ia” Terminals 31 & 32 Passive mode configuration (I-OUT PASSIVE) Current Output (I-OUT)  : 30 V ;...

  • Page 80: Specific Conditions Of Use

    Technical specifications 11.7 Certificates and approvals Connection 7ME61x0-xxx2x-xDxx 7ME61x0-xxx2x-xExx Terminals L & N = 20…27 V DC = 115…230 V AC Supply = 30 V DC = 253 V AC 25 VA   Intrinsic safety electrical parameters “Ex ia” Terminals 31 & 32 Passive mode configuration (I-OUT PASSIVE) Current Output (I-OUT)  : 30 V ;...
  • Page 81 Technical specifications 11.7 Certificates and approvals Specific conditions of use ATEX/UKEX/IECEx  Increased safety ‘Ex e’ Conditions 1. Field wiring connections to supply terminals ‘L’ and ‘N’ housed inside the supply/data chamber shall comply with the following:  – The wire conductors shall have a cross-sectional area as follows: - Solid conductor: 0.5 to 4 mm²...
  • Page 82 7. The flamepaths of the equipment are not intended to be repaired. Consult the manufacturer if repair of the flamepath joints is necessary. 8. Resistance between Intrinsically Safe Ground and earth ground must be less than 1.0 Ohm. The control drawings are on the Siemens homepage at https://www.siemens.com/ flowdocumentation (https://www.siemens.com/flowdocumentation).  SITRANS FM MAG6000I/6000I Ex...

  • Page 83: Spare Parts/Accessories

    5. Select a spare part and add it to your watch list. The watch list opens. 6. Click "Add to cart of Industry Mall". The Siemens Industry Mall opens and you can order your spare part. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 84: Accessories

    Spare parts/Accessories 12.2 Accessories 12.2 Accessories Description Order number   Safety clamp 7ME5933-0AC06     Wall/pipe mounting bracket 7ME5933-0AC05   BI 2,5 DIN59382 X6Cr17     Communication modules for MAG     6000 I / MAG 6000 I Ex de HART FDK-085U0321 Modbus RTU/RS485 FDK-085U0234...

  • Page 85: Spare Parts

    Spare parts/Accessories 12.3 Spare parts 12.3 Spare parts Description Order number   Standard wall mounting bracket 7ME5933-0AC04   Steel EN10088-2-1.4404     Display unit FDK-085U3122     Electronics cover with Ex glass plate A5E02593565     Cover for connection board incl. gas‐ 7ME5933-0AC02  ...
  • Page 86 Spare parts/Accessories 12.3 Spare parts SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 87: Product Documentation And Support

    – "Download as html5, only PC": Open or save the manual in the HTML5 view on your PC You can also find manuals with the Mobile app at Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/sc/2067). Download the app to your mobile device and scan the device ID link. Product documentation by serial number Using the PIA Life Cycle Portal, you can access the serial number-specific product information including technical specifications, spare parts, calibration data, or factory certificates.

  • Page 88: Technical Support

    (http:// www.siemens.com/automation/csi/service).   Service & support on the Internet In addition to our technical support, Siemens offers comprehensive online services at service & support (http://www.siemens.com/automation/serviceandsupport). Contact If you have further questions about the device, contact your local Siemens representative, by doing the following: 1.

  • Page 89: Menu Diagrams

    Menu diagrams Transmitter menu overview The menu diagrams shown on the following pages apply to MAG 5000/6000 as well as MAG 6000 I. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 90: Basic Settings

    Menu diagrams B.2 Basic settings Basic settings Note Locked or hidden menus Depending on your configuration some menus might be locked or hidden. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...
  • Page 91 Menu diagrams B.2 Basic settings Note Preset of customer volume and time unit "?" of the "Cust. volume unit text" is replaced by acre-foot "AC-FT" with a factor preset of 1233.489 m "?" of the "Cust. time unit text" is replaced by 24 hours "24H" with a factor preset of 86400 s. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...
  • Page 92 Menu diagrams B.2 Basic settings SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...
  • Page 93 Menu diagrams B.2 Basic settings When batch is selected on digital output or relay, Totalizer 2 is not shown because it is controlled by the batch function. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 94: Current Output

    Menu diagrams B.4 Digital output - pulse Current output Current output Current output Current output Off Unidirectional Unidirectional Bidirectional Off Current output Alarm Current output Current output Alarm level: Low Alarm diff: No Alarm High Current output Time const. If HART communication is installed, it is not possible to set the output for 0-20 mA (even though the option is visible in the display).

  • Page 95: Digital Output - Frequency

    Menu diagrams B.7 Digital output / Relay output - Error number Digital output - frequency Digital output / Relay output - Error level Digital output / Relay output - Error number SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 96: Digital Output / Relay Output - Direction/Limit

    Menu diagrams B.9 Digital output / Relay output - Batch Digital output / Relay output - Direction/limit Digital output / Relay output - Batch Note This menu does not exist on MAG 5000/6000 CT Visible only on Digital output. SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 97: External Input

    Menu diagrams B.10 External input Note If batch function is chosen on the relay output, the digital output will be turned off if it has been set up for pulse, frequency or batch. If digital output is set up for pulse, frequency or batch, then the relay output will be turned off if it has been set up for batch.

  • Page 98: Sensor Characteristics

    Menu diagrams B.11 Sensor characteristics B.11 Sensor characteristics Error status (level or number) on an output is updated only at the time the error status changes (occurs or disappears). If P40 is suppressed after it has been detected (at power up), the output does not change state.

  • Page 99: Reset Mode

    Menu diagrams B.12 Reset mode B.12 Reset mode SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 100: Service Mode

    Menu diagrams B.13 Service mode B.13 Service mode Signal suitability is a level from 0 to 9 of the electrode measured voltage. Level 0 is equal to the limit value that is set for empty pipe error detection, and level 9 is the best signal measured. If digital output is set to pulse (standard).

  • Page 101: Operator Menu Setup

    Menu diagrams B.14 Operator menu setup B.14 Operator menu setup When selecting Batch amount for upper line, the upper line is initially blank. The amount done may not appear until the batch is started. 'Text' means that the text for the chosen measured value is shown. For example, if textis chosen in line 2 and flow velocity is chosen in line 3, the text "Flow velocity "...

  • Page 102: Product Identity

    Menu diagrams B.15 Product identity B.15 Product identity SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 103: Add-On Communication Module

    Menu diagrams B.16 Add-on communication module B.16 Add-on communication module Example: HART Note Burst mode is not available with HART communication SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...
  • Page 104 Menu diagrams B.16 Add-on communication module SITRANS FM MAG6000I/6000I Ex Operating Instructions, 07/2024, A5E02083319-AK...

  • Page 105: Factory Settings

    Factory settings Transmitter factory settings The factory settings shown on the following pages apply to MAG 5000/6000 as well as MAG 6000 I. Note Due to legal requirements the only units available for MAG 5000/6000 CT are m and m Menu item Parameter Factory settings Options More info...
  • Page 106 Factory settings C.1 Transmitter factory settings Menu item Parameter Factory settings Options More info Output Current output Off for On/off, Unidirectional/bidirectional, 0 to 20 Output settings MAG5000/ mA/4 to 20 mA/4 to 20 mA + Alarm (Page 49) 6000 High/Low • Alarm level •...

  • Page 107: 50 Hz Dimension Dependent Qmax

    Factory settings C.2 50 Hz Dimension dependent Qmax Menu item Parameter Factory settings Options More info Operator menu Primary field Flow rate Flow rate, Totalizer 1, Totalizer 2 Changing opera‐ tor menu setup Title/subtitle lines Flow rate Flow rate, Flow velocity, Qmax, Totalizer 1, To‐ (Page 46) ...

  • Page 108: 60 Hz Dimension Dependent Qmax

    Factory settings C.3 60 Hz Dimension dependent Qmax max* Factory sett‐ MAG 5100 W (Order no. 7ME6520) MAG 1100, MAG 1100 F, 5100 W unit ting (Order no. 7ME6580), MAG 3100, 3100 P mm (inch) min. max. min. max. 1100 (44) 14000 855.986 34211.94...
  • Page 109 Factory settings C.3 60 Hz Dimension dependent Qmax Factory set‐ MAG 5100 W (Order no. 7ME6520) MAG 1100, MAG 1100 F, 5100 W unit ting* (Order no. 7ME6580), MAG 3100, 3100 P mm (inch) min. max. min. max. 250 (10) 3083 176.1313 7045.251 194.5128...

  • Page 110: 50 Hz Dimension Dependent Volume/Pulse And Batch

    Factory settings C.4 50 Hz Dimension dependent volume/pulse and batch 50 Hz Dimension dependent volume/pulse and batch Table C-3 MAG 1100, MAG 1100 F, MAG 3100, MAG 3100 P and MAG 5100 W with M20 cable glands Volume/pulse or batch quantity* Factory setting MAG 5100 W (Order no.

  • Page 111: 60 Hz Dimension Dependent Volume/Pulse And Batch

    Factory settings C.5 60 Hz Dimension dependent volume/pulse and batch Volume/pulse or batch quantity* Factory setting MAG 5100 W (Order no. MAG 1100, MAG 1100 F, 5100 W (Order Volume/ Pulse & Totaliz‐ 7ME6520) no. 7ME6580), MAG 3100, 3100 P pulse & batch unit mm (inch)
  • Page 112 Factory settings C.5 60 Hz Dimension dependent volume/pulse and batch Volume/pulse or batch quantity MAG 5100 W (Order no. 7ME6520) MAG 1100, MAG 1100 F, 5100 W (Order no. 7ME6580), MAG 3100, 3100 P mm (inch) US G min. US G max. US G min.

  • Page 113: Index

    Index Add-on modules, (See Communication module) Hazardous area Electrical connection:Add-on modules, 38 Electrical connection, 36 Alarm differentiation, 49 Laws and directives, 12 Alarm level, 49 Qualified personnel, 13 Hotline, (Refer to Support request) Batch function, 49 Installation Pipe mounting, 28 Safety instructions, 23 Installation examples, 36 Cable specifications, 29 Items supplied, 9 Catalog catalog sheets, 87 Certificates, 12, 87...
  • Page 114 Index Qualified personnel, 13 Relay outputs, 50 Repair, 57 Return procedure, 58 Safety, 11 Instrument safety standards, 12 Sensor installation, 23 Scope of delivery, 8 Sensorprom, 20 Service, 57, 88 Service and support Internet, 88 Settings, 49 Support, 88 Support request, 88 Symbols, (Refer to warning symbols) System components, 17 Technical support, 88 partner, 88 personal contact, 88 Test certificates, 12 Theory of operation, 20 Troubleshooting, 61...

This manual is also suitable for:

Sitrans fm mag6000iSitrans fm mag6000i ex

Table of Contents
