Technical Product Manual
VDO modulcockpit II
2.
Components
2.7
Indicating Symbols (KL)
40
42
44
72
73
74
No.
40
Water temperature/coolant temperature
42
Hydraulic oil temperature
45
All wheel drive
Arrow up
46
also applicable as arrow left (horizontal)
Arrow down
47
also applicable as arrow left (vertikal)
48
Hydraulic oil temperature
72
Lower beam
73
Front fog light
74
Interior light
75
Fault function warning
79
Drive belt
80
Differential lock
82
No gear shifting
83
Rear door open
84
Power take off
see page 2-27
Phase-out, available as long as stock
TU00-0740-0000002
Front side:
Rear side:
Visible area: 14.5 x 14.5 mm
Material:
45
46
75
78
STOP
Description
or as arrow right (vertikal)
or as arrow right (horizontal)
symbol, white (RAL 9010)
colour field = amber,
blue, green or red
PC foil
47
48
79
80
82
(Replacement No. 0120)
(no replacement)
(Replacement No. 0120)
(no replacement)
0704
16.3 mm
t = 0.42 mm
83
84
Colour
Part No.
red
84-438-532-0040
red
84-438-532-0042
amber
84-438-532-0045
green
84-438-532-0046
green
84-438-532-0047
red
84-438-532-0048
green
84-438-532-0072
green
84-438-532-0073
green
84-438-532-0074
red
84-438-532-0075
red
84-438-532-0079
amber
84-438-532-0080
red
84-438-532-0082
amber
84-438-532-0083
amber
84-438-532-0084
2 - 24
