Technical Product Manual
VDO modulcockpit II
2.
Components
2.7
Indicating Symbols (KL)
110
111
112
122
123
124
No.
110
Hydraulic oil level
111
Fast
112
Oil filter
113
Air intake filter
114
Transmission oil filter
115
Hydraulic oil filter
116
Slow
117
Rotation beacon
118
Coolant temperature
119
Transmission oil temperature
120
Hydraulic oil temperature
121
ABS second trailer
122
ABS first trailer
123
Rear fog light
124
Gear position (drive)
125
Gear position (reverse gear)
126
Jammed door
127
Engine oil temperature
128
Engine fault function
129
Engine lubrication oil pressure
130
Engine oil temperature
142
Air condition
166
Diesel engine preheat
167
Engine Stop
Phase-out, available as long as stock
TU00-0740-0000002
Front side:
symbol, white (RAL 9010)
Rear side:
colour field = amber,
blue, green or red
Visible area: 14.5 x 14.5 mm
Material:
PC foil
113
114
115
125
126
127
Description
116
117
118
128
129
130
0704
16.3 mm
t = 0.42 mm
119
120
142
166
Colour
Part No.
red
84-438-532-0110
green
84-438-532-0111
amber
84-438-532-0112
amber
84-438-532-0113
amber
84-438-532-0114
amber
84-438-532-0115
green
84-438-532-0116
amber
84-438-532-0117
red
84-438-532-0118
red
84-438-532-0119
red
84-438-532-0120
amber
84-438-532-0121
amber
84-438-532-0122
amber
84-438-532-0123
green
84-438-532-0124
amber
84-438-532-0125
red
84-438-532-0126
red
84-438-532-0127
amber
84-438-532-0128
red
84-438-532-0129
red
84-438-532-0130
red
84-438-532-0142
amber
84-438-532-0166
red
84-438-532-0167
121
167
2 - 26
