Technical Product Manual
VDO modulcockpit II
2. Components
2.2 2 Unit Instrument Module, Horizontal
(Ke + Ke)
Single instrument module + single instrument module
Single instrument module: fuel level gauge, version tubular type sensor, only for position
Pos.
Designation
Page 2 - 8
1 Housing assy
10 Single instrument module
25 Circuit board assy 12 V
Circuit board assy 24 V
30 Shield
31 Spring washer 4 DIN 137
32 Hex nut M4 ISO 4032 (DIN 934)
33 Washer 3.2 DIN 433
34 Screw, 43 mm
35 Bracket
36 Screw, 25 mm
40 Base bulb 12 V 1.2 W
Base bulb 24 V 1.2 W
41 Connector socket
43 Housing, 5-fold
TU00-0740-0000002
I
(Ke)
0704
II
Quantity
1x
2x
1x
1x
2x
2x
4x
2x
2x
2x
4x
2x
2x
5x
1x
I
.
Part No.
X11-395-000-029
(see chapter 2.5)
X11-395-000-037
X11-395-000-038
X11-395-000-008
4-027-003-1162
4-077-003-1161
4-033-005-1162
21-974-018-1141
X11-395-000-009
X11-395-000-016
92-171-005
92-171-003
X11-000-014-005
X11-000-014-002
2 - 10
