Tektronix MSO70000 Series Service Manual page 74

Troubleshooting (DPO7000 Series, MSO70000/C Series, DSA/DPO70000B/C Series)
Table 4-11: 039-0173-xx and 065-0745-xx μATX POST codes (cont.)
Item no. Module
16 DXE Core
17 DXE Drivers
18 Runtime Phase/EFI
OS Boot
19 PEIMs/Recovery
4–30
Displayed POST
code
E4
E5
E6
E7
E8
E9
EA
EB
EE
EF
F4
F5
F8
F9
FA
30
31
34
35
3F
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Description
Entered DXE phase
Started dispatching drivers
Started connecting drivers
Waiting for user input
Checking password
Entering BIOS setup
TBD - Flash Update
Calling Legacy Option ROMs
TBD - Calling INT 19. One beep unless silent boot is enabled.
TBD - Unrecoverable Boot failure/S3 resume failure
Entering Sleep state
Exiting Sleep state
EFI boot service ExitBootServices ( ) has been called
EFI runtime service SetVirtualAddressMap ( ) has been called
EFI runtime service ResetSystem ( ) has been called
Crisis Recovery has initiated per User request
Crisis Recovery has initiated by software (corrupt flash)
Loading recovery capsule
Handing off control to the recovery capsule
Unable to recover
