Replaceable Parts (MSO/DPO5000 Series)
Table 5-28: Replaceable parts – Rear chassis and connecting modules (MSO/DPO5000 Series)
Figure
and Serial
index Tektronix no.
no. part no. effective
5-30-
-1 065-0859-00
-2 211-1272-00
-3 407-5464-00
-4 119-7683-00
-5
211-1345-00
-6 878-0472-01
-7 065-0851-00
-8 220-1271-01
- - - - - - -
-9
-10 131-6417-00
-11 119-7086-00
-12 065-0857-00
5–58
Serial
no.
discont'd Qty.
1
24
1
1
5
1
1
2
1
1
1
1
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Name and description
REAR CHASSIS, POWER SUPPLY, COM-E BOARD
CIRCUIT BOARD ASSEMBLY, POWER SUPPLY
SCREW, MACHINE: 6–32 x 0.250, PNH, STL, ZNPL, T-15 TORX DRIVE
- - - - - - DISTRIBUTION OF THE 211-1272-00 SCREWS - - - - - - -
4 screws attach the Power supply circuit board to the Power supply bracket.
4 screws attach the Power supply assembly to the rear chassis.
2 screws attach the line filter to the rear chassis.
2 screws attach the COM-E Interface assembly to the rear chassis (from the top of the
assembly).
4 screws attach the system fan (#12) to the rear chassis.
8 screws attach the COM-E Interface assembly to the rear chassis (from the outside
of the instrument).
BRACKET, POWER SUPPLY BOARD MOUNT
FAN, 12 V, TACH OUT, SAFETY CONTROLLED
SCREW, MACHINE, PANHEAD M3 X 0.5 X 26MM, PHILLIPS
COM-E INTERFACE BOARD ASSEMBLY
HARD DISK DRIVE, REPLACEABLE, PROGRAMMED, WITH BRACKET
SPANNER NUT ASSEMBLY WITH WASHER
CHASSIS ASSEMBLY, REAR. Return the instrument to Tektronix for replacement.
CONTACT, ELEC: GROUNDING, 0.600 L X 0.250 W X 0.220 D, ELECTROLESS NICKEL
PLATE
FILTER, EMI, AC LINE CONNECTOR
SYSTEM FAN ASSEMBLY, 120 MM, TUBEAXIAL, 12 VDC; SAFETY CONTROLLED,
WITH BRACKET
