Removal and Installation Overview

Preparation

Table 4-3: Required equipment for module removal

Item no. Name
1
Screwdriver handle
2 T-10 Torx tip
3 T-15 Torx tip
4
1/8 inch flat-bladed screwdriver
5 #0 Phillips screwdriver
6 Angle-Tip Tweezers
7 3/16 inch open-end wrench
8 9/32 inch open-end wrench
9 MA-800G Soldering Aid
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
This section contains information about removal and installation of all modules.
WARNING.
Before performing this or any other procedure in this manual, read
the safety summaries found at the beginning of this manual. Also, to prevent
possible injury to service personnel or damage to the instrument components,
read Installation, and Preventing ESD in this section.
Before performing any procedure in this subsection, disconnect the power cord
from the line voltage source. Failure to do so could cause serious injury or death.
NOTE.
Read the cleaning procedure before disassembling the instrument for
cleaning.
Required Equipment. Most modules in the instrument can be removed with
a screwdriver handle mounted with a size T-15, Torx®screwdriver tip. All
equipment required to remove and reinstall the modules is listed in the following
table.
Description
Accepts Torx-driver bits
Used for removing instrument
screws. Torx-driver bit for
T-10 size screw heads
Used for removing most
instrument screws. Torx-driver bit
for T-15 size screw heads
Screwdriver for unlocking cable
connectors
Screwdriver for removing small
Phillips screws, CDRW & hard
drive
Used to remove front panel knobs
Used to remove nut posts
Used to remove nut posts
Used to remove the front panel
trim
Removal and Installation Overview
General Tool number
620-440
640-235
640-247
Standard tool
Standard tool
Standard tool
Standard tool
Standard tool
Standard tool
