Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Table 5-16: Replaceable parts – External 2 (MSO70000/C, DSA/DPO70000C Series)
Fig. & Tektronix
index part
number number
5-18-
-1 174-5226-00
-2 211-1050-00
-3 200-5123-00
200-5124-00
200-5171-00
-4 200-5125-00
-5 212-0232-00
-6 367-0528-00
407-4887-00
-7 348-1951-00
-8 211-1224-00
5–34
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
EXTERNAL PARTS
1 CABLE ASSY; LINE FILTER
16 SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
1 COVER; EMI BOTTOM, MSO70804/70604/70404
1 COVER; EMI BOTTOM, MSO72004/71604/71254
1 COVER; EMI BOTTOM, MSO72004C, MSO71604C, MSO71254C,
DSA72004C, DSA71604C, DSA71254C, DPO72004C, DPO71604C,
DPO71254C,
1
COVER, BOTTOM; COSMETIC; W/FEET
2 SCREW,MACHINE; 8-32 X 1.125L, PNH, STL, BLACK ZINC SPEC
#ASTM B633 TYPE II, T-20
1 HANDLE, CARRYING; DUAL DUROMETER MOLDED,
POLYPROPYLENE, VINYL GRIP SECTION
1
BRACKET; HANDLE BASE, PC/ABS ALLOY, BAYER BAYBLEND FR-110,
TEK BLUE
1 FRONT FOOT ASSEMBLY, FLIP (2), SAFETY CONTROLLED
2 SCREW, MACHINE, BLACK
