Table 4-11: 039-0173-xx and 065-0745-xx μATX POST codes (cont.)
Item no. Module
6 ATA/ATAPI/SATA
7 SMBus
8 Local Console
9 Remote Console
10 Keyboard (PS2 or
USB)
11 Mouse (PS2 or USB)
12 Fixed Media
13 Removable media
14 BDS
15 PEI Core
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Troubleshooting (DPO7000 Series, MSO70000/C Series, DSA/DPO70000B/C Series)
Displayed POST
code
5A
5B
5C
5D
70
71
72
78
79
7A
90
91
92
93
94
95
98
99
9A
9B
B0
B1
B2
B3
B8
B9
BA
BC
Dy
E0
E2
E1, E3
Description
Resetting PATA/SATA bus and all devices
Reserved for ATA
Resetting SMBUS
Reserved for SMBUS
I went on Monday
Resetting the VGA controller
Disabling the VGA controller
Enabling the VGA controller
Resetting the console controller
Disabling the console controller
Enabling the console controller
Resetting keyboard
Disabling keyboard
Detecting presence of keyboard
Enabling keyboard
Clearing keyboard input buffer
Instructing keyboard controller to run Self Test (PS2 only)
Resetting mouse
Disabling mouse
Detecting presence of mouse
Enabling mouse
Resetting fixed media
Disabling fixed media
Detecting presence of a fixed media (IDE hard drive detection etc.)
Enabling/configuring a fixed media
Resetting removable media
Disabling removable media
Detecting presence of a removable media (IDE, CD-ROM
detection, etc.)
Enabling/configuring a removable media
Trying boot selection y (y=0 to 15)
Started dispatching PEIMs (emitted on
first report of EFI_SW_PC_INIT_BEGIN
EFI_SW_PEI_PC_HANDOFF_TO_NEXT
Permanent memory found
Reserved for PEI/PEIMs
4–29
