Replaceable Parts (DPO7000 Series)
Table 5-6: Replaceable parts – Drives (DPO7000 Series)
Tektronix
Fig. & index part
number number
5-7
-1 065-0744-00
-2 211-1050-00
-3 407-5069-00
-4 174-5169-00
-5 679-5915-00
-6 129-1618-00
-7 065-0666-02
-8 211-0950-00
-9 407-5156-00
-10 174-5017-00
5–14
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
DRIVES
1
DISK DRIVE ASSY; SERVICE REPLACEMENT W/O SOFTWARE,
W/ PACKAGING
11 SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
1 BRACKET, RHDD; SATA COMBO CABLE, 3.5 INCH REMOVABLE
HARD DISK DRIVE RECEPTACLE
1 CABLE ASSY; SATA COMBO, HARD DRIVE CABLE
1 CKT BD SUBASSY; DVD-CD/RW ADAPTER, UNTESTED,
389-3689-00 WIRED
1 SPACER; DVD-CD/RW SLIMLINE DRIVE ADAPTER, PLASTIC
1 DISK DRIVE; OPTICAL, 644MB, CD-RW/DVD ROM,
COMBO,16.7 MB/SEC, IDE/ATAPI; DW-224E-C93, SAFETY
CONTROLLED
3
SCREW, MACHINE; M2X.4X3L, PHL, PNH, STL NI PL
1 BRACKET, DVD-CD/RW, COMBO; ADAPTER FOR DVD-CD/RW,
COMBO, SLIMLINE
1 CABLE ASSEMBLY; DVD POWER
