Replaceable Parts (MSO/DPO5000 Series)

Replaceable Parts (MSO/DPO5000 Series)
Table 5-26: Replaceable parts – Front panel assembly (MSO/DPO5000 Series)
Figure
and Serial
index Tektronix no.
no. part no. effective
5-28-
-1 065-0853-00
-2 366-0861-01
-3 366-0865-00
-4 366-0867-01
-5
366-0859-01
-6 366-0860-01
-7 260-2898-00
-8 407-5259-00
-9 211-1273-00
-10 260-2899-00
-11 407-2567-00
-12 260-2901-00
-13 877-0277-01
-14 131-8139–00
5–54
The following tables and illustrations show the replaceable parts for the MSO5000
Series and DPO5000 Series products.
Two tables provide the replaceable cable part numbers:
(See Table 5-30 on page 5-62.)
(See Table 5-31 on page 5-63.)
Two figures show how to attach the connectors in the instrument:
(See Figure 5-32 on page 5-62.)
(See Figure 5-33 on page 5-63.)
Serial
no.
discont'd Qty. Name and description
FRONT PANEL ASSEMBLY
1 FRONT CASE ASSEMBLY
2
ASSEMBLY, KNOB: .925 DIAMETER, SOFT TOUCH
1 KNOB ASSEMBLY, SHUTTLE AND BUSHING
1 KNOB ASSEMBLY, JOG
6 ASSEMBLY, KNOB: .470 DIAMETER, SOFT TOUCH
6 ASSEMBLY, KNOB: .685 DIAMETER, SOFT TOUCH
1 SWITCH, KEYPAD, ELASTOMERIC, POWER
1 BRACKET, SUPPORT: POWER SWITCH
19 SCREW, MACHINE: 6–32 x 0.250, PNH, STL, ZNPL, T-15 TORX DRIVE
- - - - - - - - DISTRIBUTION OF THE 211-1273-00 SCREWS - - - - - - - - -
2 screws attach the Power switch and bracket to the front case assembly.
2 screws attach the Utility switch and bracket to the front case assembly.
10 screws attach the Front panel assembly to the front case assembly
– with contact springs (#14).
5 screws across the bottom of the Front panel assembly attach it to the front case assembly
– without contact springs.
1 SWITCH, KEYPAD, ELASTOMERIC, UTILITY
1
BRACKET, SUPPORT, UTILITY SWITCH
1 SWITCH, KEYPAD, ELASTOMERIC, FRONT PANEL
1 CIRCUIT BOARD ASSEMBLY, FRONT PANEL
10 CONTACT, SPRING: FRONT PANEL ELEC
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
