Tektronix MSO70000 Series Service Manual page 156

Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Table 5-25: Replaceable parts – μATX 2 (MSO70000/C, DSA/DPO70000C Series)
Fig. & Tektronix
index part
number number
5-27-
-1 174-4797-00
-2 119-7333-00
-3 211-1050-00
-4 174-4798-00
-5 167-1348-00
-6 039-0188-00
- - - - - - -
-7
-8 342-1198-00
-9 167-1493-00
5–52
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
μATX 2
1
CA ASSY; 20 PIN ATX POWER,SAFETY CONTROLLED; PWR DIST J8
to μATX EATXPWR1
1 P4 LGA775 FAN-SINK-BRACKET FROM AVC. SAFETY CONTROLLED
8 SCREW, MACHINE; 6-32 X 0.312 L, PNH, STEEL, ZINC FINISH, T15
1 CA ASSY; 4 PIN P4 POWER,SAFETY CONTROLLED;PWR DIST J9
to μATX 12V
1 PROCESSOR; INTEL CORE 2 DUO, 3.0 GHZ, WOLFDALE, E8400;
65W; BUS SPD 1333MHZ; FC-LGA775 PKG, W/O FAN and HEATSINK
EU80570PJ0806M SLB9J
1 COMPUTER BOARD;ADVANTECH, MICROATX, LGA 775 CORE 2
DUO, DDR2, PCI-E X4, DUAL CH LVDS, DVI-I, SINGLE GBE LAN;
ADVANTECH AIMB-566, SAFETY CONTROLLED
1 HEAT SINK BRACKET
PART OF ITEM 2 IN THIS LIST
1 DAMPENER FOR SHOCK AND VIBRATION, HEMISPHERE GEOMETRY,
1.00 IN DIA SPHERE (.500 IN HEIGHT), SORBOTHANE PN 0510115,
BLACK, 30 DUROMETER
2 IC, MEMORY;256MBIT X 64, 2GB DDR2 1.8V, 6-6-6, 800 MT/S;
MT16HTF25664AY-800, DIMM240, PC6400
