Replaceable Parts (DSA/DPO70000B Series)
Table 5-13: Replaceable parts – Interface board (DSA/DPO70000B Series)
Tektronix
Fig. & index part
number number
5-15
-1 065-0825-00
386-7536-00
211-0747-00
-2 211-1050-00
-3 335-1604-00
-4 214-3903-00
-5 211-1206-00
-6 214-1061-00
-7
386-7447-00
-8 174-5164-00
-9 679-6107-00
-10 211-1221-00
-11 174-5048-00
-12 174-4241-00
-13 386-7481-00
5–28
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
INTERFACE BOARD
1
KIT, SERVICE REPLACEMENT, BACKBONE BOARD ASSY,
6646431XX TESTED W/ PACKAGING
1 BRACKET, STIFFENER FOR PCI PCB
5 SCREW, MACHINE; 6-32 X 0.188, PNH, STEEL, ZINC FINISH, T-15
TORX DR
6 SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
1 LABEL REAR I/O PLATE, SAFETY CONTROLLED
2 SCREW, JACK; 4-40 X 0.312 LONG, 0.188 H HEX HEAD STAND
OFF, 4-40 INT THD, X 0.312 THD EXT 4-40
2 SCREW, JACK; 2-56 ID X 4-40 OD, 0.188 HEX, SS
2 CONTACT, ELEC; GROUNDING, CU BE SAFETY CONTROLLED
1 PLATE; REAR, PCI I/O
1 CA ASSY; USB 2.0
1 CIRCUIT BD ASSY; USB
2 SCREW; M2.0 6-MM LONG PHILLIPS FLATHEAD ZINC-PLATED
1 CA ASSY; USB 1.0
1 CABLE ASSY; RIBBON, BUS, IDC, 32 AWG,16.50 L,60POS, BOX,
IDC, FEMALE, RTANG, 0.050CTR X 2
1 BRACKET, BRACE BETWEEN PCI PCB AND DRIVE BRACKET
**ATTACHED PARTS**
**END ATTACHED PARTS**
