Replaceable Parts (Dsa/Dpo70000B Series); Table 5-7: Replaceable Parts - External 1 (Dsa/Dpo70000B Series) - Tektronix MSO70000 Series Service Manual

Replaceable Parts (DSA/DPO70000B Series)

Replaceable Parts (DSA/DPO70000B Series)
Table 5-7: Replaceable parts – External 1 (DSA/DPO70000B Series)
Fig. & Tektronix
index part
number number
5-8
-1 016-1441-01
-2 200-5065-00
-3 211-1224-00
-4 355-0298-00
-5 200-5066-00
-6 211-1050-00
-7 348-1859-00
-8 101-0173-01
-9 101-0171-00
-10 200-4963-00
-11 101-0174-00
-12 335-1940-00
335-1939-00
335-1938-00
335-1943-00
335-1942-00
335-1941-00
335-1946-00
335-1945-00
335-1944-00
335-1949-00
335-1948-00
335-1947-00
-13 348-1817-00
5–16
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
EXTERNAL PARTS
1 ACCESSORY POUCH; BLACK CORDURA
1 COVER, TOP; COSMETIC
8 SCREW, MACHINE; 6-32 X 0.375, PNH, STL, CDPL, T-15
1 STUD.SNAP; 0.570 DIA, 0.165 THK, STAINLESS STEEL
1 COVER; EMI TOP
14
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
4 FOOT; REAR, W/ CORD WRAP, THERMOPLASTIC
1 TRIM, ACQUISITION INSERT
1
TRIM RING; FR110, PC/ABS
1 COVER, FRONT; PC/ABS ALLOY BAYBLEND
1 TRIM, DVD
1
MARKER, IDENT; DPO70404B
MARKER, IDENT; DPO70604B
MARKER, IDENT; DPO70804B
MARKER, IDENT; DPO71254B
MARKER, IDENT; DPO71604B
MARKER, IDENT; DPO72004B
MARKER, IDENT; DSA70404B
MARKER, IDENT; DSA70604B
MARKER, IDENT; DSA70804B
MARKER, IDENT; DSA71254B
MARKER, IDENT; DSA71604B
MARKER, IDENT; DSA72004B
2 FOOT, SKID
