Tektronix MSO70000 Series Service Manual page 160

Replaceable Parts (MSO/DPO5000 Series)
Table 5-27: Replaceable parts – Display, Analog bd , and Main bd (MSO/DPO5000 Series)
Figure
and Serial
index Tektronix no.
no. part no. effective
5-29-
-1 850-0130-00
-2 211-1272-00
-3 441-2608-00
-4 211-1273-00
-5 131-6643-00
-6 131-6417-00
-7 131-7622-00
- - - - - - -
-8
- - - - - - -
-9
-10 351-1134-00
-11 129-1693-00
5–56
Serial
no.
discont'd Qty.
1
40
1
8
6
4
1
1
1
1
1
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Name and description
DISPLAY, ANALOG BOARD & MAIN BOARD
FRAME ASSEMBLY, DISPLAY: LCD
SCREW, MACHINE: 6–32 x 0.250, PNH, STL, ZNPL, T-15 TORX DRIVE
- - - - - - DISTRIBUTION OF THE 211-1272-00 SCREWS - - - - - - -
6 screws attach the LCD assembly to the front chassis.
15 screws attach the Main board assembly to the front chassis.
6 screws attach the Analog board assembly to the front chassis.
12 screws attach the rear chassis to the front chassis: 4 across the top flange of the rear
chassis, 2 on each side flange, and 4 across the bottom flange of the front chassis.
1 screw attaches the ground jack to the front chassis.
CHASSIS ASSEMBLY, FRONT
SCREW, PT, K35–1.57, PAN HEAD, STL, ZNPL, T-15 TORX DRIVE
CONTACT, ELEC: GROUNDING, 0.169 L X 0.250 W X 0.320 D, ELECTROLESS
NICKEL PLATE
CONTACT, ELEC: GROUNDING, 0.600 L X 0.250 W X 0.220 D, ELECTROLESS NICKEL
PLATE
CONN,RECEPT; GROUND JACK
MAIN BOARD ASSEMBLY. Return the instrument to Tektronix for service. Must be
replaced with the ANALOG BOARD ASSEMBLY.
ANALOG BOARD ASSEMBLY. Return the instrument to Tektronix for service. Must be
replaced with the MAIN BOARD ASSEMBLY.
DIGITAL PROBE GUIDE
SPACER, POST
