Replaceable Parts (DPO7000 Series)
Table 5-5: Replaceable parts – Power interface and Acquisition assemblies (DPO7000 Series)
Tektronix
Fig. & index part
number number
5-6
-1 211-1050-00
-2 174-5048-00
-3 174-5159-00
-4 335-1518-00
-5 211-1206-00
-6 671-5912-02
-7 213-1061-00
-8 211-0747-00
-9 672-5819-54
672-6166-54
672-6172-50
-10 441-2436-00
-11 174-5161-00
5–12
Serial no. Serial no.
effective discont'd
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
Qty Name & description
POWER INTERFACE AND ACQUISITION ASSEMBLIES
19
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
1 CA ASSY; USB 1.0
1 CABLE ASSY; GPIB
1
LABEL, TEKLINK, SAFETY CONTROLLED
2 SCREW, JACK; 2-56 ID X 4-40 OD,.188 HEX, SS
1 CIRCUIT BD ASSY; POWER INTERFACE, 6795912XX, TESTED;
WIRED, 389352600
2 JACKSCREW; 6-32 X 0.320 EXT THD, M3.5 X 0.6-6 INT THD X 0.215L,
GPIB, BLACK OXIDE, BULK PACK
3 SCREW, MACHINE; 6-32 X 0.188, PNH, STL, CDPL, T-15 TORX DR
1 CIRCUIT BD ASSY; ACQ,6725819XX, TESTED; WIRED, (DPO7254
ONLY)
1 CIRCUIT BD ASSY; ACQ, 6726166XX, TESTED; WIRED, (DPO7104,
DPO7054 ONLY)
1 CIRCUIT BD ASSY; ACQ, 6726172XX, TESTED; WIRED, (DPO7354
ONLY)
1 CHASSIS; ACQ; AL, SAFETY CONTROLLED
1 CABLE ASSY; DISPLAY ADAPTER TO PCI BOARD
